For given analog signal xa(t) what is the maximum frequency of this signal and what is...

For given analog signal xa(t) what is the maximum frequency of this signal and what is the Nyquist rate for this signal (choose the minimum one)

xa(t)=5 cos(310pi t) + 8 sin(420pi t)

engineering   Electrical-Engineering
0 0
Add a comment Improve this question Transcribed image text
Next > < Previous
Sort answers by oldest

Homework Answers

Answer #1

211) - 500 (310174) + 8 sin (420114) < W = 3/01T W2 = 420 1T maximum frequne Wmax max (W7, W2) 42011 rad sec fmax = 42011 = 2
