Use the Slope-Deflection Method to analyse the structure of Figure 1 and draw the shear force, axial force, and bending moment diagrams 4 m (1.5 EI) 20 KN/m 10 KN/m 50 kN.m Figure 1
Use the Slope-Deflection Method to analyse the structure of Figure 1 and draw the shear force, axial force, and bending moment diagrams 4 m (1.5 EI) 20 KN/m 10 KN/m 50 kN.m Figure 1
Q1. Two rigid members (BCDE and EKN) are connected by a pin at E. The structure is supported by a pin at B and two rollers at D and N. An inclined distributed load is acting between E and K with the horizontal (12 kN/m) and vertical (16 kN/m) components. Neglect own weights and thicknesses of the members. f w 26.667 kN/m, 1.5m Draw necessary free body diagrams and determine the reaction forces at roller supports (D and N) and...
A simply supported prismatic beam is loaded with a load applied at an angle at point F as shown below The beams connecting points CE and EF can be considered rigid (l-very large). The magnitude of the applied load P is 75kN. NOTE: You must use your student number to calculate the magnitude of the angle, α, and the length EF using the expressions below. The angle, α, is given in degrees and the unit for length EF is m...
Problem 1: The frame shown represents the front part of a simple one bay structure in North York. The structure comprises a floor slab monolithically connected to the longitudinal and transverse beams. The structure is to be designed for snow, self-weight, and an earthquake force accounting for 12% of the building weight acting at the center of mass (slab center). Find the design values for ULS (moment, shear and axial load) of the column at the base, at the beam...
1. The number of equilibrium equations available in 2D is 6. 2. The Method of Sections results in a 2D rigid body equilibrium problem. 3. Indeterminate trusses can only be solved by Method of Joints, not Sections. 4. By definition, truss members must be pin connected & carry only axial load. 5. Shear Force is the first derivative of Bending Moment. 6. Distributed Load is the integral of Shear Force. 7. The maximum Bending Moment is always at the center...
Problem 3 Analyze the frame structure subjected to the following support movements: a beam-end settlement at Node #4; . a column base rotation at (Node #1). All members have a constant bending stiffness El and are considered as axially rigid. a) Determine the degree of kinematic indeterminacy (DKI) and show the independent DOFs. b) Assemble the structure stiffness matrix Kg. c) Assemble the structure fixed-end force vector Po. Then solve for nodal displacement vector Us based on the equations of...
QUESTION 2 [30 Marks) The framed structure shown in Figure 2 has simple supports (i.e. is free to rotate) at joints A and G. Members AC and GE are vertical, while CE and EH are horizontal. There is an internal moment release at joint C. A uniformly distributed load of 5 kN/m is applied between D and E, and another uniformly distributed load of 4 kN/m is applied between F and G as shown. There is also a horizontal point...
26.23 The moment distribution method in structural analysis can be treated as: Displacement method Force method Flexibility method First order approximate method 26.24 The method of moment distribution in structural analysis is: An approximate one An interative method An exact one None of the above 26.25 The strain energy method in structural analysis is based on the minimization of the energy with respect to: Strains Force Stress Displacement 26.26 The minimization of potential energy in structural analysis results in: Equilibrium...
Write the MATLAB code and use the function linsolve() to solve
the system of linear equations.
Thank you!
l Truss A truss is a structure that typically consists of 1. All straight members 2. connected together with pin joints 3. connected only at the ends of the members 4. and all external forces (loads&reactions) must be applied only at the joints. The weights of the members may be neglected. The basic building block of a truss is a triangle. Large...
Figure 1 shows the layout of countershaft used to transmit power to a blower through a pulley drive (4-5). Pulley (driving sheave) 4 has a diameter of 125-mm and pulley (driven sheave) 5 has a diameter of 75 mm. Pulley 5 is mounted vertically below pulley 4 (as shown in the figure). Belt tension on the loose side is 20% of the tension on the tight side. A power of 7.5 kW is transmitted via the gear set (2-3) from...
