6. (20 points) Consider the RLC circuit shown in the figure. Data: Resistace: Frequency: 1.89×103 Hz, Capacitance: 6.10×103 F, Vrms = 94.9 V, Inductance: a 175-mH 51x 102 Ω, (a) Select True, False for the following statements. True or False ?: Energy is dissipated in the resistor but not in either the capacitor or the inductor. True or False?: The current through the inductor always equals the current charging/discharging the capacitor. True or False ?: The current through the inductor is the same as the current through the resistor at all times. True or False ?: The voltage drop across the resistor is the same as the voltage drop across the inductor at all times (b) Calculate the impedance at the voltage source?
