N&R = Nilsson and Riedel 1, (20 pts) A series RLC circuit has R=10kQ, L=0.1mH, and C=10μF. what type of damping 2, (20 pts) For the circuit below, find R for critical damping. Numerical Answer 1209, work is exhibited by this circuit. must be shown for credit. R1 60Ω C1 L1 0.01 F 4 H R2
