A capacitor is charged to a potential of 11.5 V and is then connected to a...

A capacitor is charged to a potential of 11.5 V and is then connected to a voltmeter having an internal resistance of 3.50 MΩ. After a time of 3.50 s the voltmeter reads 3.0 V.

(a) What is the capacitance?
_____ F

(b) What is the time constant of the circuit?
______ s

science   physics
0 0
Add a comment Improve this question Transcribed image text
Next > < Previous
Sort answers by oldest

Homework Answers

Answer #1

VVo Re 6 3 II.S tt.SPlease rate my answer...

0 1
Add a comment
Know the answer?
Add Answer to:
A capacitor is charged to a potential of 11.5 V and is then connected to a...
Your Answer:

Post as a guest

Your Name:

What's your source?

Earn Coins

Coins can be redeemed for fabulous gifts.

Log In

Sign Up

Not the answer you're looking for? Ask your own homework help question. Our experts will answer your question WITHIN MINUTES for Free.
Similar Homework Help Questions

  • A capacitor is charged to a potential of 10.5 V and is then connected to a...

    A capacitor is charged to a potential of 10.5 V and is then connected to a voltmeter having an internal resistance of 3.20 M2. After a time of 3.50 s the voltmeter reads 3.0 V (a) What is the capacitance? (b) What is the time constant of the circuit?

  • A capacitor is charged to a potential of 12.0 V and is then connected to a...

    A capacitor is charged to a potential of 12.0 V and is then connected to a voltmeter having an internal resistance of 3.70 MΩ . After a time of 3.90 s the voltmeter reads 3.1 V Part A What is the capacitance? Part B What is the time constant of the circuit?

  • A capacitor is charged to a potential of 12.0 V and is then connected to a...

    A capacitor is charged to a potential of 12.0 V and is then connected to a voltmeter having an internal resistance of 3.10 M Ohms. After a time of 4.20 s the voltmeter reads 2.8 V. A. What is the capacitance (F)? B. What is the time constant of the circuit (s)?

  • QUESTION 6 A capacitor is charged to a potential of 12 V and is then connected...

    QUESTION 6 A capacitor is charged to a potential of 12 V and is then connected to a voltmeter having an internal resistance of 3.7 M. After a time of 4 s the voltmeter reads 2 V. What is the capacitance? (Give your answer in decimal using nF (nano Farad) as unit) QUESTION 6 A capacitor is charged to a potential of 12 V and is then connected to a voltmeter having an internal resistance of 3.7 M. After a...

  • Part A Constants A capacitor is charged to a potential of 12.0 V and is then...

    Part A Constants A capacitor is charged to a potential of 12.0 V and is then connected to a voltmeter having an internal resistance of 3.50 M2. After a time of 3.90 s the voltmeter reads 2.8 V. What is the capacitance? 0 AEO O ? You may want to review (Pages 862-866). C- For related problemsolving tips and strategies, you may want to view a Video Tutor Solution of Discharging a capacitor. Submit Request Answer Part B What is...

  • In the circuit shown in the following figure, the voltage across the R1 = 5.50 Ohm...

    In the circuit shown in the following figure, the voltage across the R1 = 5.50 Ohm resistor is 27.0 V. what are the emf of the battery and the current through the 6.00-Ohm resistor? (Let R2 = 1.00 Ohm) Epsilon = _____ V I = __________ A A capacitor is charged to a potential of 13.0 V and is connected to a voltmeter having an internal resistance of 3.45 Mohm. After a time of 3.50 s the voltmeter reads 3.0...

  • A 1.15 μF capacitor, initially charged to 13.5 V , discharges when it is connected in...

    A 1.15 μF capacitor, initially charged to 13.5 V , discharges when it is connected in series with a resistor. Part A What resistance is necessary to cause the capacitor to have only 37% of its initial charge 2.00 s after starting? (MΩ ) Part B What is the voltage across the capacitor at t = 5 τ if the capacitor is instead charged by the same battery through the same resistor? (v)

  • A capacitor that is initially uncharged is connected in series with a resistor and an emf...

    A capacitor that is initially uncharged is connected in series with a resistor and an emf of source epsilon = 100 V and negligible internal resistance. Just after the circuit is completed, the current through the resistor is 7.1 x 10^-3 A. the time constant for the circuit is 6.0 s. What is the resistance of the resistor? _____ Ohm What is the capacitance of the capacitor __________ MuF

  • A charged capacitor is connected to a resistor and a switch in a given electrical circuit....

    A charged capacitor is connected to a resistor and a switch in a given electrical circuit. The circuit has a time constant of 2.0 s. Find the capacitance if it resistance is R = 280 kΩ?

  • A capacitor that is initially uncharged is connected in series with a resistor and a 407.1...

    A capacitor that is initially uncharged is connected in series with a resistor and a 407.1 Vemf source with negligible internal resistance. Just after the circuit is completed, the current through the resistor is 0.850 mAand the time constant for the circuit is 6.20 s. Part A: What is the resistance of the resistor? Part B: What is the capacitance of the capacitor
