A carbon resistor is to be used as a thermometer. On a winter day when the...

Question

Question

A carbon resistor is to be used as a thermometer. On a winter day when the...

A carbon resistor is to be used as a thermometer. On a winter day when the temperature is 4.0 ∘C, the resistance of the carbon resistor is 218.0 Ω . Part A What is the temperature on a spring day when the resistance is 215.2 Ω ? (Take the reference temperature T0 to be 4.0 ∘C.)

science physics

Add a comment Improve this question Transcribed image text

Answer 1

Answer #1

Add a comment

Answer 2
