In the early 1900s, Robert Millikan used small charged droplets of oil, suspended in an electric...
In the early 1900s, Robert Millikan used small charged droplets of oil, suspended in an electric field, to make the first quantitative measurements of the electron’s charge. A 0.74-μm-diameter droplet of oil, having a charge of +e+e, is suspended in midair between two horizontal plates of a parallel-plate capacitor. The upward electric force on the droplet is exactly balanced by the downward force of gravity. The oil has a density of 860 kg/m3, and the capacitor plates are 6.0 mm apart.
1.What must the potential difference between the plates be to hold the droplet in equilibrium?
Homework Answers
![= (860) 13.14)(0.37 xid)] (M = 1.82 xlokg) it from eg. 40 = (1.82x1016) (9.8) (6.0 x1031 1-6 X1019 10 = 66.885 v](http://img.homeworklib.com/questions/5eae48a0-1bfa-11ec-8300-0999a0985b59.png?x-oss-process=image/resize,w_560)
Add Answer to:
In the early 1900s, Robert Millikan used small charged droplets
of oil, suspended in an electric...
Oil Drop 11. Robert Millikan received a Nobel Prize for determining the charge on the electron....
Oil Drop 11. Robert Millikan received a Nobel Prize for determining the charge on the electron. To do this, he set up a of oil between potential difference between two horizontal parallel metal plates. He then sprayed drops the plates and adjusted the potential difference until drops of a certain size between the plates, as shown above. Suppose that when the potential difference adjusted until the electric field is 10,000 N/C downward, a certain drop with a mass of remains...
In 1909, Robert Millikan was the first to find the charge of an electron in his...
In 1909, Robert Millikan was the first to find the charge of an electron in his now-famous oil-drop experiment. In that experiment tiny oil drops were sprayed into a uniform electric field between a horizontal pair of oppositely charged plates. The drops were observed with a magnifying eyepiece, and the electric field was adjusted so that the electric force on some negatively charged oil drops was just sufficient to balance their weight. Millikan accurately measured the charges on many oil...
Millikan Experiment 4
Consider an oil droplet of mass andcharge . We want to determine the charge on thedroplet in a Millikan-type experiment. We will do this in several steps. Assume, for simplicity, that the charge is positive and that the electric field betweenthe plates points upward.Oil has a density of . An oildroplet is suspended between two plates apart by adjusting the potential difference between them to . When the voltage is removed, the droplet falls and quickly reaches constant speed. It...
Millikan Experiment 2
Consider an oil droplet of mass andcharge . We want to determine the charge on thedroplet in a Millikan-type experiment. We will do this in several steps. Assume, for simplicity, that the charge is positive and that the electric field betweenthe plates points upward.The field is easily determined by knowing thespacing between the plates and measuring the potential difference applied to them. The larger problem is to determine the mass of a microscopic droplet. Consider amass falling through a viscous...
1. A small droplet of oil with a mass of 2.00 x 10-15 kg is given...
1. A small droplet of oil with a mass of 2.00 x 10-15 kg is given a small excess charge and is then held suspended in a region of uniform electric field directed upward with a magnitude of 6125 N/C. a) Is the excess charge positive or negative? b) How many elementary charges (unbalanced electrons or protons) are on the oil droplet? Note: this is the famous Millikan Oil Drop Experiment. Millikan took into account the air friction and buoyancy...
Millikan measured the electron's charge by observing tiny charged oil drops in an electric field. Each...
Millikan measured the electron's charge by observing tiny charged oil drops in an electric field. Each drop had a charge imbalance of only a few electrons. The strength of the electric field was adjusted so that the electric and gravitational forces on a drop would balance and the drop would be suspended in air. In this way the charge on the drop could be calculated. The charge was always found to be a small multiple of 1.6e-19 C. Find the...
Millikan measured the electron's charge by observing tiny charged oil drops in an electric field. Each...
Millikan measured the electron's charge by observing tiny charged oil drops in an electric field. Each drop had a charge imbalance of only a few electrons. The strength of the electric field was adjusted so that the electric and gravitational forces on a drop would balance and the drop would be suspended in air. In this way the charge on the drop could be calculated. The charge was always found to be a small multiple of 1.6e-19 C. Find the...
a) An oil droplet with a mass of 7.20 x 10-16 kg is moving upward at...
a) An oil droplet with a mass of 7.20 x 10-16 kg is moving upward at a constant speed of 2.0 m/s between two horizontal charged plates. If the electric field strength between the plates is 2.20 x 104 V/m what is the charge on the oil droplet? Express your answer in the format of a.bc x 10-de C b) In a Millikan-type experiment, two horizontal charged plates are 2.5 cm apart. A latex sphere of 1.3 x 10-15 kg...
A positively charged oil drop has a mass of 2.76 * 10^-14 kg. It is suspended...
A positively charged oil drop has a mass of 2.76 * 10^-14 kg. It is suspended in an electric field of 4.2 * 10^5 N/C between 2 parallel plates with a capacitance of 2 uf spaced 3 cm apart. a.) What is the charge on the drop? b.) How many electrons is the drop missing? c.) What is the electric potential across the plates? d.) How much charge is stored on each plate? e.) How much energy is stored in...
A tiny charged pellet of mass m is suspended at rest by the electric field between...
A tiny charged pellet of mass m is suspended at rest by the electric field between two horizontal, charged metallic plates. the lower plate has a charge and the upper plate has a negative charge. Which statement in the answers below is NOT true. a) The electric field between the plates points vertically upward. b) The pellet is negatively charged. c) The magnitude of the electric force on the pellet is equal to mg. d) If the magnitude of charge...
Oil Drop 11. Robert Millikan received a Nobel Prize for determining the charge on the electron. To do this, he set up a of oil between potential difference between two horizontal parallel metal plates. He then sprayed drops the plates and adjusted the potential difference until drops of a certain size between the plates, as shown above. Suppose that when the potential difference adjusted until the electric field is 10,000 N/C downward, a certain drop with a mass of remains...
1. A small droplet of oil with a mass of 2.00 x 10-15 kg is given a small excess charge and is then held suspended in a region of uniform electric field directed upward with a magnitude of 6125 N/C. a) Is the excess charge positive or negative? b) How many elementary charges (unbalanced electrons or protons) are on the oil droplet? Note: this is the famous Millikan Oil Drop Experiment. Millikan took into account the air friction and buoyancy...
Millikan measured the electron's charge by observing tiny charged oil drops in an electric field. Each drop had a charge imbalance of only a few electrons. The strength of the electric field was adjusted so that the electric and gravitational forces on a drop would balance and the drop would be suspended in air. In this way the charge on the drop could be calculated. The charge was always found to be a small multiple of 1.6e-19 C. Find the...
