A long straight wire has a current of 5 A running in the -z direction and the wire has a length of 2 meters

A long straight wire has a current of 5 A running in the -z direction and the wire has a length of 2 meters. It is placed in a uniform magnetic field of 0.1 T in the -x direction. What is the magnetic force on the wire?

0.10 Newton in the-x direction.

1.0 Newton in the -y direction.

1.0 Newton in the ty direction

1.0 Newton in the +x direction.

science   physics
1 0
Add a comment Improve this question Transcribed image text
Next > < Previous
Sort answers by oldest

Homework Answers

Answer #1

0 0
