A straight wire of length 0.5 m carries a current of 5 A in the positive...

Question

Question

A straight wire of length 0.5 m carries a current of 5 A in the positive x direction lying in

a uniform magnetic field B = ( 0.9 j – 0.4 k) T. Find the magnetic force exerted on the wire.

science physics

Answer 1

Answer #1

Answer 2

Similar Homework Help Questions

A 5 cm length of wire carries a current of 4.0 A in the positive z...

A 5 cm length of wire carries a current of 4.0 A in the positive z direction. The force on this wire due to a magnetic field direction, the force on the wire is F-0.2 k N. Find the magnetic field is F (-0.2 1+0.2j) N. If this wire is rotated so that the current flows in the positive x Ti T k
A wire aligned along the z-axis carries a current of 6.7 Amp. in the positive z-direction. Find the force (magnitude and direction) exerted on a 6.4 cm long length of the wire by a uniform magneti...

A wire aligned along the z-axis carries a current of 6.7 Amp. in the positive z-direction. Find the force (magnitude and direction) exerted on a 6.4 cm long length of the wire by a uniform magnetic field with magnitude 0.95 T in the positive y-direction. A wire aligned along the z-axis carries a current of 6.7 Amp. in the positive z-direction. Find the force (magnitude and direction) exerted on a 6.4 cm long length of the wire by a uniform...
A straight wire carries a current of 10 A at an angle of 30* with respect...

A straight wire carries a current of 10 A at an angle of 30* with respect to the direction of a uniform 0.30 T magnetic field. Find the angle the magnitude of the magnetic force on a 0.50 m length of the wire.

A wire aligned along the z-axis carries a current of 6.7 Amp. in the positive z-direction....

A wire aligned along the z-axis carries a current of 6.7 Amp. in the positive z-direction. Find the force (magnitude and direction) exerted on a 6.4 cm long length of the wire by a uniform magnetic field with magnitude 0.95 T in the positive y-direction.
A wire carries a steady current of 2.00 A. A straight section of the wire is...

A wire carries a steady current of 2.00 A. A straight section of the wire is 0.750 m long and lies along the y axis within a uniform magnetic field, = 2.00 T. If the current is in the negative y direction, what is the magnetic force on the section of wire? Find magnitude. Already know direction is - x axis thank you
A wire 109.0 cm long lying along the x axis carries a current of 360.0 mA...

A wire 109.0 cm long lying along the x axis carries a current of 360.0 mA in the positive x direction, through a magnetic field B = (0.0048 T)i + (0.0036 T)j + (0.0007 T)k. Find the magnitude of the force on the wire.

A 1.50 m long straight wire lies along the z axis and carries a steady current...

A 1.50 m long straight wire lies along the z axis and carries a steady current in the +z direction. A uniform magnetic field exists everywhere in space and is given by B⃗→ = (3.00 i^ + 4.00 j^) T. If the field exerts a force on the wire of magnitude 60.0 N, find the current carried by the wire.
10. A wire bent at a right angle carries a current I = 3.0 A, as...

10. A wire bent at a right angle carries a current I = 3.0 A, as shown below. The length of each straight side of the wire is 2.0 m, as shown. 2.0 m I = 3.0 A I = 3.0 A 2.0 m If this wire is in a region where there is a uniform magnetic field B =-(2.0 T) k , find the net magnetic force exerted on the wire. (Give this force in component form.) (10 pts)
A long wire lying along the x-axis carries a current of 2.80 A in the +x...

A long wire lying along the x-axis carries a current of 2.80 A in the +x direction. There is a uniform magnetic field present, given by B=0.003 i + 0.004 j + 0.002 k, where i,j,k are the unit vectors along the cartesian coordinate axes in units of Tesla. Calculate the y-component of the magnetic force acting on a segment of wire of length L = 21.5 cm.

3. A long wire lying along the x-axis carries a current of 2.00 A in the...

3. A long wire lying along the x-axis carries a current of 2.00 A in the +x direction. There is a uniform magnetic field present, given by B-0.00+ 0.002j+0.003k, where i, j, k are the unit vectors along the cartesian coordinate axes) in units of Tesla. (a) Calculate the y-component of the magnetic force acting on a segment of wire of length L-20.0 cm. (b) Calculate the z-component of the magnetic force.
