Please explain how to find the sum of two 16-bit integers. For example, 0 1 1...

Question

Question

Please explain how to find the sum of two 16-bit integers. For example,

0 1 1 0 0 1 1 0 0 1 1 0 0 1 1 0

0 1 0 1 0 1 0 1 0 1 0 1 0 1 0 1

engineering Computer-Science

Answer 1

Answer #1

Ex: 0+0=0

0+1=1

1+1=1 and carry 1

0 1 1 0 0 1 1 0 0 1 1 0 0 1 1 0 + 0 1 0 1 0 1 0 1 0 1 0 1 0 1 0 1= 0 1 0 1 1 1 0 1 1 1 0 1 1 1 0 1 1

Answer 2
