The current through a coil as a function of time is represented by the equation I(t)...
The current through a coil as a function of time is represented by the equation I(t) = Ae−bt sin(ωt), where A = 5.25 A, b = 1.75 ✕ 10−2 s−1, and ω = 375 rad/s. At t = 0.640 s, this changing current induces an emf in a second coil that is close by. If the mutual inductance between the two coils is 4.34 mH, determine the induced emf. (Assume we are using a consistent sign convention for both coils. Include the sign of the value in your answer.)
Homework Answers
Add Answer to:
The current through a coil as a function of time is represented
by the equation I(t)...
Two coils are close to each other. The first coil carries a current given by i(t)...
Two coils are close to each other. The first coil carries a current given by i(t) = 5.20e-0.0250t sin 120nt, where i is in amperes and t is in seconds. At t = 0.805 s, the emf measured across the second coil is -2.35 V. What is the mutual inductance of the coils? mH
Two coils are close to each other. The first coil carries a current given by i(t)...
Two coils are close to each other. The first coil carries a current given by i(t) = 5.60e−0.0250t sin 120πt, where i is in amperes and t is in seconds. At t = 0.775 s, the emf measured across the second coil is −2.50 V. What is the mutual inductance of the coils? mH
Coil 1 has L1 = 40 mH and N1 = 101 turns. Coil 2 has L2...
Coil 1 has L1 = 40 mH and N1 = 101 turns. Coil 2 has L2 = 41 mH and N2 = 234 turns. The coils are fixed in place; their mutual inductance M is 5.6 mH. A 6.1 mA current in coil 1 is changing at the rate of 4.4 A/s. (a) What magnetic flux Φ12 links coil 1, and (b) what self-induced emf appears in that coil? (c) What magnetic flux Φ21 links coil 2, and (d) what...
Coil 1 has L1 = 50 mH and N1 = 113 turns. Coil 2 has L2...
Coil 1 has L1 = 50 mH and N1 = 113 turns. Coil 2 has L2 = 72 mH and N2 = 233 turns. The coils are fixed in place; their mutual inductance M is 5.5 mH. A 7.3 mA current in coil 1 is changing at the rate of 7.3 A/s. (a) What magnetic flux Φ12 links coil 1, and (b) what self-induced emf appears in that coil? (c) What magnetic flux Φ21 links coil 2, and (d) what...
Coil 1 has L1 = 26 mH and N1 = 102 turns. Coil 2 has L2...
Coil 1 has L1 = 26 mH and N1 = 102 turns. Coil 2 has L2 = 59 mH and N2 = 216 turns. The coils are fixed in place; their mutual inductance M is 6.3 mH. A 8.4 mA current in coil 1 is changing at the rate of 4.5 A/s. (a) What magnetic flux Φ12 links coil 1, and (b) what self-induced emf appears in that coil? (c) What magnetic flux Φ21 links coil 2, and (d) what...
Coil 1 has L1 = 50 mH and M, = 104 turns. Coil 2 has L2...
Coil 1 has L1 = 50 mH and M, = 104 turns. Coil 2 has L2 = 68 mH and M2 = 227 turns. The coils are fixed in place; their mutual inductance M is 3.6 mH. A 8.0 mA current in coil 1 is changing at the rate of 4.8 A/s. (a) What magnetic flux D12 links coil 1, and (b) what self-induced emf appears in that coil? (c) What magnetic flux D21 links coil 2, and (d) what...
Please show the derivation of the formulas! Coil 1 has L1 = 25 mH and N1...
Please show the derivation of the formulas!
Coil 1 has L1 = 25 mH and N1 = 100 turns. Coil 2 has L2 = 40mH and N2 = 200 turns. The coils are fixed in place; their mutual inductance M is 3.0 mH. A 6.0 mA current in coil 1 is changing at the rate of 4.0 A/s. (a) What magnetic flux 012 links coil 1, and (b) what self-induced emf appears in that coil? (c) What magnetic flux 021...
Two coils are close to each other. The first coil carries a current given by i(t)...
Two coils are close to each other. The first coil carries a current given by i(t) = 5.90e−0.0250t sin 120πt, where i is in amperes and t is in seconds. At t = 0.815 s, the emf measured across the second coil is −3.15 V. What is the mutual inductance of the coils?
An emf of 9.2 ✕ 10−3 V is induced in a coil while the current in...
An emf of 9.2 ✕ 10−3 V is induced in a coil while the current in a nearby coil is decreasing at a rate of 8.7 A/s. What is the mutual inductance of the two coils (in H)?
a. A coil of wire with 209 circular turns of radius 3.10 cm is in a...
a. A coil of wire with 209 circular turns of radius 3.10 cm is in a uniform magnetic field along the axis of the coil. The coil has R = 41.5 Ω . At what rate, in teslas per second, must the magnetic field be changing to induce a current of 0.149 A in the coil? b. A closely wound rectangular coil of 90.0 turns has dimensions of 30.0 cm by 47.0 cm . The plane of the coil is...
Two coils are close to each other. The first coil carries a current given by i(t) = 5.20e-0.0250t sin 120nt, where i is in amperes and t is in seconds. At t = 0.805 s, the emf measured across the second coil is -2.35 V. What is the mutual inductance of the coils? mH
Coil 1 has L1 = 50 mH and M, = 104 turns. Coil 2 has L2 = 68 mH and M2 = 227 turns. The coils are fixed in place; their mutual inductance M is 3.6 mH. A 8.0 mA current in coil 1 is changing at the rate of 4.8 A/s. (a) What magnetic flux D12 links coil 1, and (b) what self-induced emf appears in that coil? (c) What magnetic flux D21 links coil 2, and (d) what...
Please show the derivation of the formulas!
Coil 1 has L1 = 25 mH and N1 = 100 turns. Coil 2 has L2 = 40mH and N2 = 200 turns. The coils are fixed in place; their mutual inductance M is 3.0 mH. A 6.0 mA current in coil 1 is changing at the rate of 4.0 A/s. (a) What magnetic flux 012 links coil 1, and (b) what self-induced emf appears in that coil? (c) What magnetic flux 021...
