An air-filled parallel-plate capacitor has plates of area 2.70 cm2 separated by 0.50 mm. The capacitor...
An air-filled parallel-plate capacitor has plates of area 2.70 cm2 separated by 0.50 mm. The capacitor is connected to a 6.0-V battery.
(a) Find the value of its capacitance.
________ pF
(b) What is the charge on the capacitor?
________ pC
(c) What is the magnitude of the uniform electric field between the
plates?
________ V/m
Homework Answers
