Question

A 0.880-mm-diameter silver wire carries a 50.0 mA current. What is the electric field in the...

A 0.880-mm-diameter silver wire carries a 50.0 mA current.

What is the electric field in the wire?

What is the electron drift speed in the wire?

science   physics
0 0
Add a comment Improve this question Transcribed image text
Next > < Previous
Sort answers by oldest

Homework Answers

Answer #1

0 0
Add a comment
Know the answer?
Add Answer to:
A 0.880-mm-diameter silver wire carries a 50.0 mA current. What is the electric field in the...
Your Answer:

Post as a guest

Your Name:

What's your source?

Earn Coins

Coins can be redeemed for fabulous gifts.

Log In

Sign Up

Not the answer you're looking for? Ask your own homework help question. Our experts will answer your question WITHIN MINUTES for Free.
Similar Homework Help Questions

  • A 0.300-mm-diameter silver wire carries a 10.0 mA current. Part A What is the electric field...

    A 0.300-mm-diameter silver wire carries a 10.0 mA current. Part A What is the electric field in the wire? Express your answer with the appropriate units. Part B What is the electron drift speed in the wire? Express your answer with the appropriate units.

  • 27.A 0.50-mm-diameter silver wire carries a 20 mA current.What are (a) the electric field and (b)...

    27.A 0.50-mm-diameter silver wire carries a 20 mA current.What are (a) the electric field and (b) the electron drift speed in the wire?

  • A silver wire of diameter 1.6 mm carries a current of 130 mA. The density of...

    A silver wire of diameter 1.6 mm carries a current of 130 mA. The density of conduction electrons in silver is 5.8 times 10^28 m^-3. How long (on average) does it take for a conduction electron to move 1.0 cm along the wire? Min

  • An aluminum wire with a diameter of 0.095 mm has a uniform electric field of 0.205...

    An aluminum wire with a diameter of 0.095 mm has a uniform electric field of 0.205 V/m imposed along its entire length. The temperature of the wire is 35.0°C. Assume one free electron per atom. (a) Use the information in this Table of Resistivities and Temperature Coefficients to determine the resistivity (in . m) of aluminum at this temperature. p= 2.m (b) What is the current density (in MA/m2) in the wire? = C MA/m2 (c) What is the total...

  • An aluminum wire with a diameter of 0.115 mm has a uniform electric field of 0.235...

    An aluminum wire with a diameter of 0.115 mm has a uniform electric field of 0.235 V/m imposed along its entire length. The temperature of the wire is 45.0°C. Assume one free electron per atom. (a) Use the information in this Table of Resistivities and Temperature Coefficients to determine the resistivity (in Ω · m) of aluminum at this temperature. ρ =  Ω · m (b) What is the current density (in MA/m2) in the wire? J =  MA/m2 (c) What is...

  • An aluminum wire with a diameter of 0.105 mm has a uniform electric field of 0.325...

    An aluminum wire with a diameter of 0.105 mm has a uniform electric field of 0.325 V/m imposed along its entire length. The temperature of the wire is 35.0°C. Assume one free electron per atom. (a) Use the information in this Table of Resistivities and Temperature Coefficients to determine the resistivity (in Ω · m) of aluminum at this temperature. ρ = _______Ω · m (b) What is the current density (in MA/m2) in the wire? J = ________MA/m2 (c)...

  • An aluminum wire with a diameter of 0.125 mm has a uniform electric field of 0.295...

    An aluminum wire with a diameter of 0.125 mm has a uniform electric field of 0.295 V/m imposed along its entire length. The temperature of the wire is 55.0° C. Assume one free electron per atom. (a) Use the information in this Table of Resistivities and Temperature Coefficients to determine the resistivity of aluminum at this temperature. ρ = 3.2e-8 Ω·m (b) What is the current density in the wire? J = MA / m2 (c) What is the total...

  • A 5.30 m length of 1.6 mm -diameter wire carries a 710 mA current when 18.0...

    A 5.30 m length of 1.6 mm -diameter wire carries a 710 mA current when 18.0 mV is applied to its ends. The drift velocity is 1.2×10−5 m/s . Part A Determine the resistance R of the wire. Part B Determine the resistivity ρ. Part C Determine the current density j. Part D Determine the electric field inside the wire. Part E Determine the number n of free electrons per unit volume.

  • A 14.0 gauge copper wire of diameter 1.628 mm carries a current of 10.0 mA ....

    A 14.0 gauge copper wire of diameter 1.628 mm carries a current of 10.0 mA . a)What is the potential difference across a 2.00 m length of the wire? b)What would the potential difference in part A be if the wire were silver instead of copper, but all else was the same?

  • A d = 3.71 mm diameter wire carries an electric current of I = 18.2 A...

    A d = 3.71 mm diameter wire carries an electric current of I = 18.2 A when the electric field is E = 5.72 times 10^-2 V/m along the wire. What is the current density? What is the conductivity of the wire? What is the resistivity of the wire?
