There is a magnetic field in a certain region of space where the field lines are...
There is a magnetic field in a certain region of space where the field lines are all parallel to the XY-plane (that is, Bz=0). When a 2.00μC charge enters this region of space with a velocity of v=(4.00i-2.00j+3.00k)x105m/s, it encounters a force F=(-0.90i+1.50j+2.20k)N. Compute the magnitude and direction of the magnetic field B.
Homework Answers
I hope you understood the problem and got your answers, If yes rate me!! or else comment for a better solutions
