Suppose that a highway offramp that I often use bends with a radius of 20 meters....
Suppose that a highway offramp that I often use bends with a radius of 20 meters. I notice that my car tires allow me (in good weather) to take this offramp at 15 m/s without slipping. How large does the offramp's bending radius need to be for me to be able to make the turn at 30 m/s instead (without slipping)?
Homework Answers
Add Answer to:
Suppose that a highway offramp that I often use bends with a
radius of 20 meters....
A flat (unbanked) curve on a highway has a radius of 250 m
A flat (unbanked) curve on a highway has a radius of 250 m. A car successfully rounds the curve at a speed of 35 m/s but is on the verge of skidding out. a. Draw free body diagram of the car. b. If the coefficient of static friction between the car's tires and the road surface were reduced by a factor of 2, with what maximum speed could the car round the curve without slipping? c. Suppose the coefficient of friction were increased...
A banked circular highway curve is designed for traffic moving at 62 km/h. The radius of...
A banked circular highway curve is designed for traffic moving at 62 km/h. The radius of the curve is 214 m. Traffic is moving along the highway at 41 km/h on a rainy day. What is the minimum coefficient of friction between tires and road that will allow cars to take the turn without sliding off the road? (Assume the cars do not have negative lift.)
015 10.0 points A highway curves to the left with radius of curvature of 34 m...
015 10.0 points A highway curves to the left with radius of curvature of 34 m and is banked at 18° so that cars can take this curve at higher speeds. Consider a car of mass 1777 kg whose tires have a static friction coefficient 0.58 against the pavement. top view R 34 m 18 rear view μ = 0.58 How fast can the car take this curve without skidding to the outside of the curve? The acceleration of gravity...
015 10.0 points A highway curves to the left with radius o curvature of 34 m...
015 10.0 points A highway curves to the left with radius o curvature of 34 m and is banked at 18° s that cars can take this curve at higher speeds Consider a car of mass 1777 kg whose tires have a static friction coefficient 0.58 against the pavement top view R-34111 18 rear view 0.58 How fast can the car take this curve without skidding to the outside of the curve? The acceleration of gravity is 9.8 m/s2. Answer...
015 10.0 points A highway curves to the left with radius of curvature of 35 m...
015 10.0 points A highway curves to the left with radius of curvature of 35 m and is banked at 16° So that cars can take this curve at higher speeds Consider a car of mass 1341 kg whose tires have a static friction coefficient 0.44 against the pavement top view R 35 m 16 rear 0. view How fast can the car take this curve without skidding to the outside of the curve? The acceleration of gravity is 9.8...
A flat (unbanked) curve on a highway has a radius of 240 m . A car...
A flat (unbanked) curve on a highway has a radius of 240 m . A car successfully rounds the curve at a speed of 37 m/s but is on the verge of skidding out. Part A If the coefficient of static friction between the car’s tires and the road surface were reduced by a factor of 2, with what maximum speed could the car round the curve? Express your answer in meters per second to two significant figures. part B...
1.On a hill Pick up trucks will often carry sand bags in the back to help...
1.On a hill Pick up trucks will often carry sand bags in the back to help with traction. Consider a truck of mass M=1500kg on a hill inclined at 5 degrees. Construct a free body diagram and use it to determine the minimum coefficient of friction so the truck does not slide down the hill. Using this coefficient of friction determine if the truck had 100 kg extra weight if it would slide down the hill or not (i.e. does...
suppose a wheel with a moment of inertia I=2.5kg*m², a radius of R=40cm, and a mass...
suppose a wheel with a moment of inertia I=2.5kg*m², a radius of R=40cm, and a mass of 6kg were spinning at 4 rad/s before being released. If it rolls without slipping, how fast will it roll? A. 1.92 m/s B. 1.36 m/s C. 1.85 m/s D. 2.17 m/s
Highway curves are "banked" inward, so gravity assists the car's traction. Suppose another highway curve has...
Highway curves are "banked" inward, so gravity assists the car's traction. Suppose another highway curve has a radius of curvature of 500m. It is banked so that traffic moving at 30m/s can travel around the curve without needing any help from friction. a) Draw a force diagram for a car traveling around this curve at a constant speed. Draw the diagram so that you are looking at the rear of the car. Do not tilt your coordinate axes for this...
7. A highway curve with a radius of R metres is banked so that cars moving at v m/s around the curve do not have to rely on friction when taking the turn. IWPS 7. No.4] 7.1 Show (from first principle...
7. A highway curve with a radius of R metres is banked so that cars moving at v m/s around the curve do not have to rely on friction when taking the turn. IWPS 7. No.4] 7.1 Show (from first principles) that the angle, 6, at which, the road should be banked is given by: 0 arctan 7.2 A particular banked highway curve with a radius of 200 m is designed for traffic moving at 60 km/h. On a rainy...
015 10.0 points A highway curves to the left with radius of curvature of 34 m and is banked at 18° so that cars can take this curve at higher speeds. Consider a car of mass 1777 kg whose tires have a static friction coefficient 0.58 against the pavement. top view R 34 m 18 rear view μ = 0.58 How fast can the car take this curve without skidding to the outside of the curve? The acceleration of gravity...
015 10.0 points A highway curves to the left with radius o curvature of 34 m and is banked at 18° s that cars can take this curve at higher speeds Consider a car of mass 1777 kg whose tires have a static friction coefficient 0.58 against the pavement top view R-34111 18 rear view 0.58 How fast can the car take this curve without skidding to the outside of the curve? The acceleration of gravity is 9.8 m/s2. Answer...
015 10.0 points A highway curves to the left with radius of curvature of 35 m and is banked at 16° So that cars can take this curve at higher speeds Consider a car of mass 1341 kg whose tires have a static friction coefficient 0.44 against the pavement top view R 35 m 16 rear 0. view How fast can the car take this curve without skidding to the outside of the curve? The acceleration of gravity is 9.8...
7. A highway curve with a radius of R metres is banked so that cars moving at v m/s around the curve do not have to rely on friction when taking the turn. IWPS 7. No.4] 7.1 Show (from first principles) that the angle, 6, at which, the road should be banked is given by: 0 arctan 7.2 A particular banked highway curve with a radius of 200 m is designed for traffic moving at 60 km/h. On a rainy...
