A 180-kg horizontal beam is supported at the ends A and B. A 330-kg piano rests...

Question

Question

A 180-kg horizontal beam is supported at the ends A and B. A 330-kg piano rests a quarter of the way from the end A.

Determine the magnitude of the vertical force on the support at A (Fa)

Determine the magnitude of the vertical force on the support at B. (Fb)

science physics

Answer 1

Answer #1

Answer 2
