A 180-kg load is hung on a wire of length of 3.30 m, cross-sectional area 2.00x10^-5...

Question

Question

A 180-kg load is hung on a wire of length of 3.30 m, cross-sectional area 2.00x10^-5 m^2, and Young's modulus 8.00x10^10 N/m^2.

What is its increase in length? mm

science physics

Answer 1

Answer #1

Answer 2
