A sample of collagen fiber with a cross-sectional area of 1.2*10^−7 m^2 is hung from a...
A sample of collagen fiber with a cross-sectional area of 1.2*10^−7 m^2 is hung from a fixed support, and a gradually increasing load is applied to the lower end. The tensile strength of collagen (i.e. its fracture stress) is 0.6*10^8 N/m^2. Estimate the load in kilograms that can be applied before the fiber breaks
we probably use the equation for breaking stress: Force(max)/Area = Y(max change in length) / length
