In a solid, shear stress is related to shear strain. In a fluid, shear stress is...
In a solid, shear stress is related to shear strain. In a fluid, shear stress is related to:
The magnitude of the shear strain
The slope of the shear strain
The time rate of change of the shear strain
The viscosity
The Reynolds' number
Flag this Question
Question 21 pts
Picture the flow of a fluid which has a non-zero viscosity in a pipe. Where is the velocity of this flow the greatest?
At the wall fo the pipe
Half way in to the center
At the center of the pipe
Flag this Question
Question 31 pts
A "Newtonian" fluid has what property?
Its density is independent of temperature
Its viscosity is independent of altitude
Its density is independent of pressure
Its viscosity is independent of flow velocity
Flag this Question
Question 41 pts
The viscosity of water changes with temperature. If you stir a pot of water for a few seconds then stop stirring, it will gradually slow down and stop.
Which will continue to flow for longer, a pot of water about to boil (at ~100° C) or one at room temperature (~ 20° C)? Explain your answer.
a pot of water about to boil (at ~100° C)
a pot of water at room temperature (~ 20° C)
Flag this Question
Question 51 pts
Imagine the flow of water through a pipe which has a radius of 10 cm. If the flow velocity in the pipe is 0.1 m/s at a distance 2 cm from the wall, what is the approximate flow velocity at the center of the pipe?
0.01 m/s
0.05 m/s
0.1 m/s
0.5 m/s
1.2 m/s
