When a current flows in an aluminum wire of diameter 4.39 mm , the drift speed...
When a current flows in an aluminum wire of diameter 4.39 mm , the drift speed of the conduction electrons is 0.000135 m/s . How many electrons are flowing past a given point each second? The conduction electron density in aluminum is 6.00 × 10 28 m ^(− 3)
Homework Answers
To find number of electrons in t =1 sec
where , e = 1.6 × 10-19 C is the
magnitude of charge on each electron.
