A 100.0 µF capacitor is charged to 12.0 V at t = 0. The capacitor is...

Question

Question

A 100.0 µF capacitor is charged to 12.0 V at t = 0. The capacitor is then allowed to

discharge through a 50 W resistor.

How long after the capacitor is allowed to discharge will its voltage be reduced to 10.0 volts?

(1) 0.91 ms (2) 3.21 ms (3) 5.47 ms (4) 7.12 ms (5) 8.96 ms

science physics

Answer 1

Answer #1

Answer 2
