Question

Design a digital system that will count the number of switches activated and display that count...

Design a digital system that will count the number of switches activated and display that count in binary using LEDs. An LED that is illuminated represents a '1' and an LED that is off represents a '0'.

  • ____ Interface 3 switches to your design

  • _____ Interface 8 LEDs to your design

  • _____ Show all circuit diagrams

  • _____ Provide any boolean logic, truth tables, karnaugh maps

I need help with the circuit diagrams and boolean logic, truth table, and K-map.

Please show all work thank you!
