A thin film appears to be green when viewed from above (λ = 550 nm). The...
A thin film appears to be green when viewed from above (λ = 550 nm). The thin film has an index of refraction n = 1.2, and lies on top of a liquid with n = 1.33. Above the thin film is air, with n = 1. What is the smallest possible (non-zero) thickness of the film?
Homework Answers
Add Answer to:
A thin film appears to be green when viewed from above (λ = 550
nm). The...
= 498.4 nm in vacuum) when viewed at normal incidence in white light. Determine the two...
= 498.4 nm in vacuum) when viewed at normal incidence in white light. Determine the two smallest, non-zero thicknesses for the soap film if its index of refraction is 1.40. 125 nm and 375 nm O 97 nm and 179 nm 89 nm and 267 nm O 100 nm and 310 nm 158 nm and 346 nm Question 22 4 pts What is the minimum (non-zero) thickness of a benzene (n = 1.546) thin film that will result in destructive...
What is the thinnest soap film (excluding the case of zero thickness) that appears black when...
What is the thinnest soap film (excluding the case of zero thickness) that appears black when viewed by reflected light with a wavelength of 480 nm? The index of refraction of the film is 1.33, and there is air on both sides of the film.
A scientist notices that an oil slick floating on water when viewed from above has many...
A scientist notices that an oil slick floating on water when viewed from above has many different rainbow colors reflecting off the surface. She aims a spectrometer at a particular spot and measures the wavelength to be 750 nm (in air). The index of refraction of water is 1.33.Part A: The index of refraction of the oil is 1.20. What is the minimum thickness of the oil slick at that spot? t= 313nmPart B: Suppose the oil had an index...
A thin soap film (n = 1.33) is supported in air. The film gives a bright...
A thin soap film (n = 1.33) is supported in air. The film gives a bright fringe when viewed at normal incidence in reflected light with λ = 550 nm. Which of the following might be the thickness of the film?
The reflection of light from the thin film of thickness t as shown in the figure...
The reflection of light from the thin film of thickness t as
shown in the figure appears violet (400nm) when viewed from above.
This means the two rays reflecting off of the two surfaces
interfere constructively. t is the minimum thickness. The dark grey
material has a higher index of refraction than the light grey with
the white being air. For what minimum thickness relative to t would
it need to be for the film to now appear red (700nm)...
N-1.00 n-1.33 n=1 50 3. A thin film of thickness t and index of refraction 1.33 coats a glass wit...
I dont understand thin film interference. Thanks in
advance
n-1.00 n-1.33 n=1 50 3. A thin film of thickness t and index of refraction 1.33 coats a glass with index of refraction 1.50 as shown above. Which of the following thicknesses t will not reflect light with wavelength 640 nm in air? (A) 160 nm (8) 240 nm (C) 360 nm (D) 480 nm 4. Lenses in fine quality cameras are coated to reduce the reflection from the lenses. If...
part d and e i want a further explanation (33 Question 19 1 A very thin...
part d and e i want a further explanation
(33 Question 19 1 A very thin film of transparent oil of refractive index_1.40 floats on a smooth hody of water of refractive index 1.33. Above the oil is air, Green light of wavelength 520 nm (in air) is incident normally on to the oil from above." green light, A=520 nm air oil, = 1.40 water, n 1.33 Do light waves reflected at the top of the oil suffer a phase...
Problem 8: Consider a thin film of of soapy water (11-1.33) on Plexiglas. Since light is...
Problem 8: Consider a thin film of of soapy water (11-1.33) on Plexiglas. Since light is a wave, there are many thicknesses of this film that will result in constructive interference. Part (a) What is the smallest non-zero thicknesses, in nanometers of this film if it appears green (constructively reflecting 550 nm light) when illuminated perpendicularly by white light? Numeric : A numeric value is expected and not an expression - Part (b) What is the second smallest non-zero thicknesses,...
A thin piece of glass with an index of refraction of n=1.50 is placed on top...
A thin piece of glass with an index of refraction of n=1.50 is placed on top of a medium that has an index of refraction n=2.0. A beam of light traveling in air (n=1.0) shines perpendicularly down on the glass. The beam contains light of only two colors, blue light with a wavelength of 450 nm and orange light with a wavelength of 600 nm. What is the minimum non-zero thickness of the glass that gives completely constructive interference for...
(17 %) Problem 3: A thin layer of oil with index of refraction no-l .47 is floating above the water. The index of refraction of water is nw 13. The index of refraction of air is na-1. A light wit...
(17 %) Problem 3: A thin layer of oil with index of refraction no-l .47 is floating above the water. The index of refraction of water is nw 13. The index of refraction of air is na-1. A light with wavelength λ = 625 nm goes in from the air to oil and water. 25% Part (a) Express the wavelength of the light in the oil, λο, in terms of λ and no. 쇼 25% Part (b) Express the minimum...
= 498.4 nm in vacuum) when viewed at normal incidence in white light. Determine the two smallest, non-zero thicknesses for the soap film if its index of refraction is 1.40. 125 nm and 375 nm O 97 nm and 179 nm 89 nm and 267 nm O 100 nm and 310 nm 158 nm and 346 nm Question 22 4 pts What is the minimum (non-zero) thickness of a benzene (n = 1.546) thin film that will result in destructive...
The reflection of light from the thin film of thickness t as
shown in the figure appears violet (400nm) when viewed from above.
This means the two rays reflecting off of the two surfaces
interfere constructively. t is the minimum thickness. The dark grey
material has a higher index of refraction than the light grey with
the white being air. For what minimum thickness relative to t would
it need to be for the film to now appear red (700nm)...
I dont understand thin film interference. Thanks in
advance
n-1.00 n-1.33 n=1 50 3. A thin film of thickness t and index of refraction 1.33 coats a glass with index of refraction 1.50 as shown above. Which of the following thicknesses t will not reflect light with wavelength 640 nm in air? (A) 160 nm (8) 240 nm (C) 360 nm (D) 480 nm 4. Lenses in fine quality cameras are coated to reduce the reflection from the lenses. If...
part d and e i want a further explanation
(33 Question 19 1 A very thin film of transparent oil of refractive index_1.40 floats on a smooth hody of water of refractive index 1.33. Above the oil is air, Green light of wavelength 520 nm (in air) is incident normally on to the oil from above." green light, A=520 nm air oil, = 1.40 water, n 1.33 Do light waves reflected at the top of the oil suffer a phase...
Problem 8: Consider a thin film of of soapy water (11-1.33) on Plexiglas. Since light is a wave, there are many thicknesses of this film that will result in constructive interference. Part (a) What is the smallest non-zero thicknesses, in nanometers of this film if it appears green (constructively reflecting 550 nm light) when illuminated perpendicularly by white light? Numeric : A numeric value is expected and not an expression - Part (b) What is the second smallest non-zero thicknesses,...
(17 %) Problem 3: A thin layer of oil with index of refraction no-l .47 is floating above the water. The index of refraction of water is nw 13. The index of refraction of air is na-1. A light with wavelength λ = 625 nm goes in from the air to oil and water. 25% Part (a) Express the wavelength of the light in the oil, λο, in terms of λ and no. 쇼 25% Part (b) Express the minimum...
