A rectanglular loop consists of 6 turns of wire carrying a current of 2.4 A. The...
A rectanglular loop consists of 6 turns of wire carrying a current of 2.4 A. The loop is in the x-y plane, and the direction of flow of the current is shown in the figure. The loop has dimensions a = 2 cm and b = 7 cm. Consider a uniform magnetic field of strength 3.9 x 10-4 T in x, y, or z directions. 1) If the uniform field of 3.9 x 10-4 T is along the +x axis, find the magnitude of the torque acting on the loop. τ =
Find the total force on side a.
Fa = N
Find the total force on side b.
Fb = N
If the uniform field of 3.9 x 10-4 T is along the +y axis, find the magnitude of the torque acting on the loop.
τ = N-m
Find the total force on side a.
Fa = N
Find the total force on side b.
Fb = N
If the uniform field of 3.9 x 10-4 T is along the +z axis, find the magnitude of the torque acting on the loop.
τ = N-m
Find the total force on side a.
Fa = N
Find the total force on side b.
Fb =
Homework Answers
still any doubts feel free to
ask at least before giving downvote
Please like
Add Answer to:
A rectanglular loop consists of 6 turns of wire carrying a
current of 2.4 A. The...
As shown in the figure, a rectangular loop with a length of 20.0 cm and a...
As shown in the figure, a rectangular loop with a length of 20.0 cm and a width w of 15.0 cm has 20 turns and carries a current of 0.130 A counterclockwise around the loop when viewed from the positive x axis. A horizontal (parallel to the x-z plane) magnetic field of magnitude 0.0510 T is oriented at an angle of 65.0° relative to the perpendicular to the loop (the positive x axis). (Assume the length and width are measured...
2. A square loop (L-0.30 m) consists of 45 closely wrapped turns, each carrying a current of 0.40...
2. A square loop (L-0.30 m) consists of 45 closely wrapped turns, each carrying a current of 0.40 A. The loop, hinged along the y-axis, is oriented as shown in a uniform magnetic field of 0.60 T directed in the positive x direction. (a) [6 pts.] What is the magnitude of the torque on the loop? (b) 12 pts] Draw magnetic moment and torque vectors in the figure. 60° (c) [2 pts.] As viewed from above, in what direction does...
HANDIN HW assignment # 11-1: A circular wire loop of 50 turns with a diameter of...
HANDIN HW assignment # 11-1: A circular wire loop of 50 turns with a diameter of 20 cm lies in the z-x plane with a magnetic moment pointing along +y and a magnetic field pointing along x-y plane in a direction making an angle of 53° with +y axis z If the magnetic field is 0.5 T and the current is 100 ma. Find a) the magnetic moment of the coil, b) the torque on the coil , and c)...
A rectangular loop of wire with sides H = 28 cm and W = 52 cm...
A rectangular loop of wire with sides H = 28 cm and W = 52 cm is
located in a region containing a constant magnetic field B = 0.9 T
that is aligned with the positive y-axis as shown. The loop carries
current I = 177 mA. The plane of the loop is inclined at an angle θ
= 35o with respect to the x-axis.
1) What is μx, the x-component of the magnetic moment
vector of the loop? A-m2...
top view side view The picture shows a rectangular current-carrying loop in a uniform magnetic field...
top view side view The picture shows a rectangular current-carrying loop in a uniform magnetic field that is directed right. The loop is free to rotate about the axis shown as the dashed line in the top view. (a) Select all the correct statements about this situation from the list below As seen from the side view, the initial net torque on the loop is clockwise As seen from the side view, the initial net torque on the loop is...
A wire loop is in the x-y plane as shown. A current I is in the...
A wire loop is in the x-y plane as shown. A current I is in the loop. A uniform magnetic field B has magnitude B0 and is in the y-z plane and makes an angle of 30degree with the z axis (60degree with the y-axis). Find the magnetic force on the left wire (FL) right wire (FR) front wire (Ff) back wire (Fbk) Find the total force on the wire.
The picture shows a rectangular current-carrying loop in a uniform magnetic field that is directed right.
The picture shows a rectangular current-carrying loop in a uniform magnetic field that is directed right. The loop is free to rotate about the axis shown as the dashed line in the top view. (a) Select all the correct statements about this situation from the list below. As seen from the side view, the initial net torque on the loop is clockwise As seen from the side view, the initial net torque on the loop is counterclockwise As seen in the top view, the...
A single-turn square loop of wire, 2.00 cm on each edge, carries a clockwise current of...
A single-turn square loop of wire, 2.00 cm on each edge, carries a clockwise current of 0.220 A. The loop is inside a solenoid, with the plane of the loop perpendicular to the magnetic field of the solenoid. The solenoid has 30.0 turns/cm and carries a clockwise current of 15.0 A. (a) Find the force on each side of the loop. magnitude µN (b) Find the magnitude of the torque acting on the loop. N · m
A rectangular loop of wire with sides H = 23 cm and W = 78 cm is located in a region
A rectangular loop of wire with sides H = 23 cm and W = 78 cm is located in a region containing a constant magnetic field B = 1.34 T that is aligned with the positive y-axis as shown. The loop carries current I = 227 mA. The plane of the loop is inclined at an angle θ = 21° with respect to the x-axis. 1) What is μx, the x-component of the magnetic moment vector of the loop? 2) What is...
Question 6 [5 marks] A rectangular loop with sides l = 30 cm and w 10 cm carries a current, I, of...
Question 6 [5 marks] A rectangular loop with sides l = 30 cm and w 10 cm carries a current, I, of 2 A and lies centered in the xy-plane as shown below. The loop is in a region where there is a uniform magnetic field. The magnetic field is given by B (2 a3 ay + 4 az) x 102 Wb/m2. Determine the total force acting on the loop and the torque acting on the loop.
Question 6 [5...
As shown in the figure, a rectangular loop with a length of 20.0 cm and a width w of 15.0 cm has 20 turns and carries a current of 0.130 A counterclockwise around the loop when viewed from the positive x axis. A horizontal (parallel to the x-z plane) magnetic field of magnitude 0.0510 T is oriented at an angle of 65.0° relative to the perpendicular to the loop (the positive x axis). (Assume the length and width are measured...
2. A square loop (L-0.30 m) consists of 45 closely wrapped turns, each carrying a current of 0.40 A. The loop, hinged along the y-axis, is oriented as shown in a uniform magnetic field of 0.60 T directed in the positive x direction. (a) [6 pts.] What is the magnitude of the torque on the loop? (b) 12 pts] Draw magnetic moment and torque vectors in the figure. 60° (c) [2 pts.] As viewed from above, in what direction does...
HANDIN HW assignment # 11-1: A circular wire loop of 50 turns with a diameter of 20 cm lies in the z-x plane with a magnetic moment pointing along +y and a magnetic field pointing along x-y plane in a direction making an angle of 53° with +y axis z If the magnetic field is 0.5 T and the current is 100 ma. Find a) the magnetic moment of the coil, b) the torque on the coil , and c)...
A rectangular loop of wire with sides H = 28 cm and W = 52 cm is
located in a region containing a constant magnetic field B = 0.9 T
that is aligned with the positive y-axis as shown. The loop carries
current I = 177 mA. The plane of the loop is inclined at an angle θ
= 35o with respect to the x-axis.
1) What is μx, the x-component of the magnetic moment
vector of the loop? A-m2...
top view side view The picture shows a rectangular current-carrying loop in a uniform magnetic field that is directed right. The loop is free to rotate about the axis shown as the dashed line in the top view. (a) Select all the correct statements about this situation from the list below As seen from the side view, the initial net torque on the loop is clockwise As seen from the side view, the initial net torque on the loop is...
A wire loop is in the x-y plane as shown. A current I is in the loop. A uniform magnetic field B has magnitude B0 and is in the y-z plane and makes an angle of 30degree with the z axis (60degree with the y-axis). Find the magnetic force on the left wire (FL) right wire (FR) front wire (Ff) back wire (Fbk) Find the total force on the wire.
Question 6 [5 marks] A rectangular loop with sides l = 30 cm and w 10 cm carries a current, I, of 2 A and lies centered in the xy-plane as shown below. The loop is in a region where there is a uniform magnetic field. The magnetic field is given by B (2 a3 ay + 4 az) x 102 Wb/m2. Determine the total force acting on the loop and the torque acting on the loop.
Question 6 [5...
