Consider an electrophysiology experiment in which a 0.200 mm diameter round silver wire is used as...
Consider an electrophysiology experiment in which a 0.200 mm diameter round silver wire is used as a stimulation electrode. In this experiment, a current of 3.77~ mA is applied through the wire. The density of free electrons in silver is 5.86 x 10^28 electrons/m^3 . Calculate the magnitude of the drift velocity of the electrons in the silver wire under these conditions. Enter your answer in units of meters/second using calculator scientific notation (e.g., 1.23e-4 for 0.000123).
Homework Answers
Add Answer to:
Consider an electrophysiology experiment in which a 0.200 mm
diameter round silver wire is used as...
A silver wire of diameter 1.6 mm carries a current of 130 mA. The density of...
A silver wire of diameter 1.6 mm carries a current of 130 mA. The density of conduction electrons in silver is 5.8 times 10^28 m^-3. How long (on average) does it take for a conduction electron to move 1.0 cm along the wire? Min
Copper wire has a diameter of 1.02 mm. It carries a current of 1.67 A to...
Copper wire has a diameter of 1.02 mm. It carries a current of 1.67 A to a 200 W bulb. The density of free electrons is 8.5x10^28 electrons per cubic meter. Find a) the current density and b) the drift velocity
Consider a silver wire which it at a temperature of 40◦ and has a diameter of...
Consider a silver wire which it at a temperature of 40◦ and has a diameter of 1.2 mm. a) What is the resistivity of the wire? b) If a field of 3.5 V/m is applied to the wire, find the current in the wire as a result. c) What is the potential difference from one end of the wire to the other to produce the current in part b) if the wire is 20 m long? d) What is the...
A 5.30 m length of 1.6 mm -diameter wire carries a 710 mA current when 18.0...
A 5.30 m length of 1.6 mm -diameter wire carries a 710 mA current when 18.0 mV is applied to its ends. The drift velocity is 1.2×10−5 m/s . Part A Determine the resistance R of the wire. Part B Determine the resistivity ρ. Part C Determine the current density j. Part D Determine the electric field inside the wire. Part E Determine the number n of free electrons per unit volume.
A 0.880-mm-diameter silver wire carries a 50.0 mA current. What is the electric field in the...
A 0.880-mm-diameter silver wire carries a 50.0 mA current. What is the electric field in the wire? What is the electron drift speed in the wire?
27.A 0.50-mm-diameter silver wire carries a 20 mA current.What are (a) the electric field and (b)...
27.A 0.50-mm-diameter silver wire carries a 20 mA current.What are (a) the electric field and (b) the electron drift speed in the wire?
An 18-gauge copper wire (diameter 1.02 mm) carries a current with a current density of 1.40×106...
An 18-gauge copper wire (diameter 1.02 mm) carries a current with a current density of 1.40×106 A/m2 . Copper has 8.5×1028 free electrons per cubic meter Calculate the current in the wire Calculate the drift velocity of electrons in the wire.
2) The number density of conduction electrons in silver is 5.86 x 1028 m-3. independent of...
2) The number density of conduction electrons in silver is 5.86 x 1028 m-3. independent of temperature. If a cylindrical wire of length L and cross-sectional area A were made of silver its electrical resistance would be given by R= ρ L A where ρ is the resistivity of the material measured in Ω−m. The resistivity can also be shown to be related to microscopic properties of the metal such as the number density of conduction electrons, the mass and...
A 14-gauge copper wire has a diameter of 1.684 mm. What magnitude current flows in amperes...
A 14-gauge copper wire has a diameter of 1.684 mm. What magnitude current flows in amperes when the drift velocity is 1.20 mm/s? (The density of free electrons in copper is 8.34 ✕ 1028 e−/m3.).) ____________ A
The current density of a silver wire is 3.20x106 A/m² . If the current and the...
The current density of a silver wire is 3.20x106 A/m² . If the current and the drift velocity of the electrons through the wire is 2.00 A and 3.20x10-4 m/s respectively. . Part A - Find the diameter of the wire and the density of free electrons. 8.92x10-4 m 6.25x1028 8.92x10-4 m , 1.25x1027 6.31*10-4 m 6.25x1028 6.31*10-4 m , 1.25x1027 7.96x10-7 m , 1.25x1027
A silver wire of diameter 1.6 mm carries a current of 130 mA. The density of conduction electrons in silver is 5.8 times 10^28 m^-3. How long (on average) does it take for a conduction electron to move 1.0 cm along the wire? Min
The current density of a silver wire is 3.20x106 A/m² . If the current and the drift velocity of the electrons through the wire is 2.00 A and 3.20x10-4 m/s respectively. . Part A - Find the diameter of the wire and the density of free electrons. 8.92x10-4 m 6.25x1028 8.92x10-4 m , 1.25x1027 6.31*10-4 m 6.25x1028 6.31*10-4 m , 1.25x1027 7.96x10-7 m , 1.25x1027
