a transformer is used to step down the voltage from 120V to 6V for use with...

a transformer is used to step down the voltage from 120V to 6V for use with an electric razor. if the razor draws a current of 0.5A, what current is drawn from the 120V lines? what is the ratio of the loops in the primary and secondary coils of the transformer?

science   physics
0 0
Add a comment Improve this question Transcribed image text
Next > < Previous
Sort answers by oldest

Homework Answers

Answer #1

0 0
Add a comment
Know the answer?
Add Answer to:
a transformer is used to step down the voltage from 120V to 6V for use with...
Your Answer:

Post as a guest

Your Name:

What's your source?

Earn Coins

Coins can be redeemed for fabulous gifts.

Log In

Sign Up

Not the answer you're looking for? Ask your own homework help question. Our experts will answer your question WITHIN MINUTES for Free.
Similar Homework Help Questions

  • A stepup transformer decreases voltage from 120V to 6V. The secondary coil has 80 turns and...

    A stepup transformer decreases voltage from 120V to 6V. The secondary coil has 80 turns and current 50A. Find power, current and number of turns in the primary coil

  • 1. A step down transformer with a turns ratio of 6 to 1 has 120V applied...

    1. A step down transformer with a turns ratio of 6 to 1 has 120V applied to its primary coil. A 25Ω load resistor is connected to the secondary coil. Calculate the following (3+2+2 -7 Points) Secondary coil voltage Secondary coil current Primary coil current a. b. c. 2. A step up transformer has a primary coil current of 1SA and an applied voltage of 220V. The secondary coil current is 5A. Calculate the following (3+3+2+2-10 Points) Secondary coil voltage...

  • The step-down transformer in a local neighborhood reduces the voltage from a 1,680 V line to...

    The step-down transformer in a local neighborhood reduces the voltage from a 1,680 V line to 120 V. (a) If there are 175 loops on the secondary, how many are on the primary coil? ______ loops (b) What current does the transformer draw from the line if the current in the secondary is 36.0 A? ________ A (c) What are the power input and output? Input: _______ W Output: ________ W

  • Part A: A transformer with turns ratio (primary/secondary) of 18:1 is used to step down the...

    Part A: A transformer with turns ratio (primary/secondary) of 18:1 is used to step down the voltage from a 120 V wall socket to be used in a battery charger. What is the voltage supplied to the recharger? Part B: The electric motor in a toy train requires a voltage of 9.0 V. Find the ratio of turns on the primary coil to the turns on the secondary coil in a transformer that will step the 120-V household voltage down...

  • A transformer steps down voltage from 1000V to 120V. The primary coil carries 2A and has...

    A transformer steps down voltage from 1000V to 120V. The primary coil carries 2A and has 1000 turn. How many turns does the secondary coil have?

  • A step-down transformer is used for a rechargeable phone. a. What is the voltage output of...

    A step-down transformer is used for a rechargeable phone. a. What is the voltage output of a transformer used for rechargeable flashlight batteries, if its primary has 400 turns, its secondary 2.5 turns, and the input voltage is 110 V? b. What input current is required to produce a 0.50 A output? c. What is the power input?

  • An ideal step-down transformer has a primary coil of 370 turns and a secondary coil of...

    An ideal step-down transformer has a primary coil of 370 turns and a secondary coil of 22 turns. Its primary coil is plugged into an outlet with 115 V, from which it draws a current of 0.29 A. (a) What is the voltage in the secondary coil? (b) Calculate the current in the secondary coil? (c) Assuming that the transformer secondary is driving a resistive load, calculate the average power dissipated in the resistor.

  • 70. A transformer with a turns ratio (secondary/primary) of 1:18 is used to step down the...

    70. A transformer with a turns ratio (secondary/primary) of 1:18 is used to step down the voltage from a 120-V wall socket to be used in a battery recharging unit. What is the voltage supplied to the recharger?

  • In an ideal 1:8 step-down transformer, the primary power is 10 kW and the primary voltage...

    In an ideal 1:8 step-down transformer, the primary power is 10 kW and the primary voltage is 4kV. What is, a) the primary current? b) the secondary voltage? c) the secondary current? The secondary is connected to a power transmission line. If the line has a resistance of 29 ㎕2m, what is the rate at which energy is being dissipated in 800 km of line? If 8:1 step up transformer is used, what is the rate at which energy is...

  • An ideal step-down transformer has a primary coil of 400 turns and a secondary coil of...

    An ideal step-down transformer has a primary coil of 400 turns and a secondary coil of 25 turns. Its primary coil is plugged into an outlet with 110 V(AC), from which it draws an rms current of 0.83 A. 1.)What is the voltage in the secondary coil? 2.)Calculate the rms current in the secondary coil. 3.)Assuming that the transformer secondary is driving a resistive load, calculate the average power dissipated in the resistor.
