An air pollutant is emitted from an urban stack with an effective height of 185m at...
An air pollutant is emitted from an urban stack with an effective height of 185m at 27 kg/s and the wind speed at the stack height is 5.3 m/s under a clear night sky.
Q: What is the ground-level concentration at a point 2000 m downwind and 300 m crosswind of the stack?
Homework Answers
Add Answer to:
An air pollutant is emitted from an urban stack with an
effective height of 185m at...
It is a clear night with a surface wind speed of 2 m/s. There is 100...
It is a clear night with a surface wind speed of 2 m/s. There is 100 g/s of a nonreactive pollutant that is released from a stack in a rural area. The physical stack height is 50 meters and there is a heat emission rate of .005 MW. A) Find the plume rise. (delta h) B) Find the ground level concentration 700m directly downwind at ground level.
31. A stack emits 120 g/s of NO2. The effective stack height is 90 m. The...
31. A stack emits 120 g/s of NO2. The effective stack height is 90 m. The windspeed at the stack. sightin t mrstanl20 a aora are ae height is 7 m/s, and the atmospheric stability class D (25 pt) (A) Estimate the concentration of NO2 on the ground at a distance 1.5 km downwind and 50 m off the downwind axis (B) What is the maximum downwind concentration of NO2 on the ground level under these conditions? (C) Where does...
Show all work Using the Briggs equation, calculate the effective stack height for a stack plume...
Show all work
Using the Briggs equation, calculate the effective stack height for a stack plume centerline at a downwind distance of 1800 ft. Stack exit gas flow: 300 cubic feet/sec, cfs (already adjusted for stack conditions,_no adjustment necessary.). 0 Exit temp 250 F Stack height 50 m Ambient temp 70 F Wind velocity 1 m/sec Atmospheric Stability B Stack diameter 1.3 m 0 Atmospheric Stability B Stack diameter 1.5 m
A plume from a smokestack has a pollutant emission rate of 1 kg/sec, at an exit...
A plume from a smokestack has a pollutant emission rate of 1 kg/sec, at an exit velocity of 10 m/sec and a temperature of 50 degrees Celsius, The stack height is 20 m, its radius is 1.5 m, and the plume is known to rise under moderately stable conditions (the measured lapse rate is -6.5 degrees Celsius/ km). The measured wind speed is 4 m/sec and the air temperature is 27 degrees celsius. Find the effective stack height to use...
Particulate matter is emitted from a stack of 50 m. The atmospheric wind is 10 miles/hr. If the stack emits only PM o 120 μm in diameter with a density of 5 g/cm, what would be the downwind dista...
Particulate matter is emitted from a stack of 50 m. The atmospheric wind is 10 miles/hr. If the stack emits only PM o 120 μm in diameter with a density of 5 g/cm, what would be the downwind distance (in meter) these particles are likely to settle on the ground?
Particulate matter is emitted from a stack of 50 m. The atmospheric wind is 10 miles/hr. If the stack emits only PM o 120 μm in diameter with a density...
(17 pt) Suppose a bonfire emits CO at the rate of 20 g/s on a clear...
(17 pt) Suppose a bonfire emits CO at the rate of 20 g/s on a clear night when the wind is blowing at 2 m/s. If the effective stack height at the fire is 6 m: (a) (6 pt) What would you expect the ground-level CO concentration to be along the centerline at 400 m downwind (in mg/m3 )? (b) (6 pt) Estimate the maximum ground-level concentration using empirical method (in mg/m3 ). (c) (4 pt) Estimate the maximum ground-level...
2. A power plant emits 300 kg of SO2 per hour into a neutral atmosphere with...
2. A power plant emits 300 kg of SO2 per hour into a neutral atmosphere with a wind speed of 2 m/s. The ơy and o, values are assumed to be 100m and 30m, respectively. Taken into consideration of the ground reflection effects: 1). what will the ground level concentration of SO2, expressed in ug/m3, if the town is 2 km off the plume centerline and the plant has a stack that produces an effective stack height of 20 meter?...
2. A power plant emits 300 kg of SO2 per hour into a neutral atmosphere with a wind speed of 2 m/s. The ơy and o, value...
2. A power plant emits 300 kg of SO2 per hour into a neutral atmosphere with a wind speed of 2 m/s. The ơy and o, values are assumed to be 100m and 30m, respectively. Taken into consideration of the ground reflection effects: 1). what will the ground level concentration of SO2, expressed in ug/m3, if the town is 2 km off the plume centerline and the plant has a stack that produces an effective stack height of 20 meter?...
both questions 3. 1 pts) The following noise record was obtained from a small shopping mall...
both questions
3. 1 pts) The following noise record was obtained from a small shopping mall in Tallahassee, Florida Determine the equivalent continuous equal energy level (Leel. Sound level (dBA) Time (h) 0000-0600 0600 -0800 0800-1000 1000 - 2000 2000-2200 2200 - 0000 (20 pts) Two oil-fired boilers for a 600 megawatt (MW) power plant produce a sound power level of 149 dB (re 10- W) at 4,000 Hz, from the induced draft fans. Determine the sound pressure level 4080...
31. A stack emits 120 g/s of NO2. The effective stack height is 90 m. The windspeed at the stack. sightin t mrstanl20 a aora are ae height is 7 m/s, and the atmospheric stability class D (25 pt) (A) Estimate the concentration of NO2 on the ground at a distance 1.5 km downwind and 50 m off the downwind axis (B) What is the maximum downwind concentration of NO2 on the ground level under these conditions? (C) Where does...
Show all work
Using the Briggs equation, calculate the effective stack height for a stack plume centerline at a downwind distance of 1800 ft. Stack exit gas flow: 300 cubic feet/sec, cfs (already adjusted for stack conditions,_no adjustment necessary.). 0 Exit temp 250 F Stack height 50 m Ambient temp 70 F Wind velocity 1 m/sec Atmospheric Stability B Stack diameter 1.3 m 0 Atmospheric Stability B Stack diameter 1.5 m
Particulate matter is emitted from a stack of 50 m. The atmospheric wind is 10 miles/hr. If the stack emits only PM o 120 μm in diameter with a density of 5 g/cm, what would be the downwind distance (in meter) these particles are likely to settle on the ground?
Particulate matter is emitted from a stack of 50 m. The atmospheric wind is 10 miles/hr. If the stack emits only PM o 120 μm in diameter with a density...
2. A power plant emits 300 kg of SO2 per hour into a neutral atmosphere with a wind speed of 2 m/s. The ơy and o, values are assumed to be 100m and 30m, respectively. Taken into consideration of the ground reflection effects: 1). what will the ground level concentration of SO2, expressed in ug/m3, if the town is 2 km off the plume centerline and the plant has a stack that produces an effective stack height of 20 meter?...
2. A power plant emits 300 kg of SO2 per hour into a neutral atmosphere with a wind speed of 2 m/s. The ơy and o, values are assumed to be 100m and 30m, respectively. Taken into consideration of the ground reflection effects: 1). what will the ground level concentration of SO2, expressed in ug/m3, if the town is 2 km off the plume centerline and the plant has a stack that produces an effective stack height of 20 meter?...
both questions
3. 1 pts) The following noise record was obtained from a small shopping mall in Tallahassee, Florida Determine the equivalent continuous equal energy level (Leel. Sound level (dBA) Time (h) 0000-0600 0600 -0800 0800-1000 1000 - 2000 2000-2200 2200 - 0000 (20 pts) Two oil-fired boilers for a 600 megawatt (MW) power plant produce a sound power level of 149 dB (re 10- W) at 4,000 Hz, from the induced draft fans. Determine the sound pressure level 4080...
