A spherical diving bell containing a camera is in the ocean at a depth of 173...
A spherical diving bell containing a camera is in the ocean at a depth of 173 m. It has a flat, transparent, circular port with a diameter of 19.5 cm. Find the total force on the port (use ρsea water = 1025 kg/m3).
____N
Homework Answers
Add Answer to:
A spherical diving bell containing a camera is in the ocean at a
depth of 173...
(a) Calculate the absolute pressure at an ocean depth of 150 m. Assume the density of...
(a) Calculate the absolute pressure at an ocean depth of 150 m. Assume the density of sea water is 1 022 kg/m3 and the air above exerts a pressure of 101.3 kPa?? Pa (b) At this depth, what is the buoyant force on a spherical submarine having a diameter of 4.80 m? N
The Mariana trench is located in the Pacific Ocean at a depth of about 11 000...
The Mariana trench is located in the Pacific Ocean at a depth of about 11 000 m below the surface of the water. The density of seawater is 1025 kg/m3. (a) If an underwater vehicle were to explore such a depth, what force would the water exert on the vehicle's observation window (radius = 0.294 m)? (b) For comparison, determine the weight of a jetliner whose mass is 3.17 × 105 kg
Show all calculations. Give answers in correct UNITS to three significant digits. 1. Some planetary scientist...
Show all calculations. Give answers in correct UNITS to three significant digits. 1. Some planetary scientist believe Mars may have had an ocean that was 0.450 km deep. The acceleration of gravity (“g”) on Mars is 3.71 m/s^2. Determine: a. The gauge pressure at the bottom of the Mars ocean. (assume freshwater) b. The depth of an ocean on Earth to achieve the same gauge pressure 2. A diving bell is designed to dive 250 m below the sea (Earth)....
the ocean at a depth where the absolut the fish? Use 1025 kg/mº for the density...
the ocean at a depth where the absolut the fish? Use 1025 kg/mº for the density of 1. A fish is swimming in the ocean at 148 kPa. How far below the surface is the fie e absolute pressure of the seawater is 25 kg/m3 for the density of seawater. b) 7.64 m b) 7.64 m c) 13.6 m a) 4.65 m c) 13.6 m d) 16.6 m e) 21.1 m
A submarine is at a depth of 54 m under the ocean surface. The Inside of...
A submarine is at a depth of 54 m under the ocean surface. The Inside of the submarine is kept at atmospheric pressure. What is the net foroe being exerted on a circular window of the submarine that has a radius ot 23 cm? The density of the ocean water is 1030 kg/m
(a) Calculate the absolute pressure at the bottom of a fresh-water lake at a depth of...
(a) Calculate the absolute pressure at the bottom of a fresh-water lake at a depth of 25.8 m. Assume the density of the water is 1.00 ✕ 103 kg/m3 and the air above is at a pressure of 101.3 kPa. Pa (b) What force is exerted by the water on the window of an underwater vehicle at this depth if the window is circular and has a diameter of 36.0 cm? N
A submarine is stranded on the bottom of the ocean with its hatch 35m below the...
A submarine is stranded on the bottom of the ocean with its hatch 35m below the surface. Calculate the minimum force (in newtons) needed to open the hatch from the inside, given it is circular and 0.450 m in diameter. Air pressure inside the submarine is 1 atm and the pressure on the ocean’s surface is also 1 atm. Take the density of seawater as 1025 kg/m3 and g=9.8 m/s2.
1. An undersea research chamber is spherical with an external diameter of 5.60 m. The mass...
1. An undersea research chamber is spherical with an external diameter of 5.60 m. The mass of the chamber, when occupied, is 68400 kg. It is anchored to the sea bottom by a cable. The density of sea water is 1025 kg/m3. Calculate the following: (express your answers using appropriate mks units.) (a) the buoyant force on the chamber (b) the tension in the cable 2. A green brass block is placed on top of a 0.17 kg yellow styrofoam...
) A scientific instrument is encased in a diving bell which has a shape that is roughly approxima...
) A scientific instrument is encased in a diving bell which has a shape that is roughly approximated by rotating the region R around the y-axis, where R is the region under the curve y arccos(x) (in meters) over the interval [0, 1]. On its most recent trip underwater, the diving bell sprung a small leak at the top and filled up with water at a depth that was half its total height. The water has constant density a in...
What is the total force acting on the outside of the spherical submarine of diameter 2.0...
What is the total force acting on the outside of the spherical submarine of diameter 2.0 m when it is 1000 m below the surface of the ocean? The pressure inside is 1.0 ATM and the density of seawater is 1020 kg / m3
the ocean at a depth where the absolut the fish? Use 1025 kg/mº for the density of 1. A fish is swimming in the ocean at 148 kPa. How far below the surface is the fie e absolute pressure of the seawater is 25 kg/m3 for the density of seawater. b) 7.64 m b) 7.64 m c) 13.6 m a) 4.65 m c) 13.6 m d) 16.6 m e) 21.1 m
A submarine is at a depth of 54 m under the ocean surface. The Inside of the submarine is kept at atmospheric pressure. What is the net foroe being exerted on a circular window of the submarine that has a radius ot 23 cm? The density of the ocean water is 1030 kg/m
) A scientific instrument is encased in a diving bell which has a shape that is roughly approximated by rotating the region R around the y-axis, where R is the region under the curve y arccos(x) (in meters) over the interval [0, 1]. On its most recent trip underwater, the diving bell sprung a small leak at the top and filled up with water at a depth that was half its total height. The water has constant density a in...
