A small steel wire of diameter 1.5 mm is connected to an oscillator and is under...

A small steel wire of diameter 1.5 mm is connected to an oscillator and is under a tension of 7.8 N . The frequency of the oscillator is 60.0 Hz and it is observed that the amplitude of the wave on the steel wire is 0.52 cm .

a) What is the power output of the oscillator, assuming that the wave is not reflected back?

b) If the power output stays constant but the frequency is doubled, what is the amplitude of the wave?
science   physics
0 0
Add a comment Improve this question Transcribed image text
Next > < Previous
Sort answers by oldest

Homework Answers

Answer #1

0 0
Add a comment
Know the answer?
Add Answer to:
A small steel wire of diameter 1.5 mm is connected to an oscillator and is under...
Your Answer:

Post as a guest

Your Name:

What's your source?

Earn Coins

Coins can be redeemed for fabulous gifts.

Log In

Sign Up

Not the answer you're looking for? Ask your own homework help question. Our experts will answer your question WITHIN MINUTES for Free.
Similar Homework Help Questions

  • A steel (density 7.86 x 103 kg/m3) wire of length 1.20 m and diameter 0.644 mm...

    A steel (density 7.86 x 103 kg/m3) wire of length 1.20 m and diameter 0.644 mm is subjected to a tension of 34.5 N. At one end of the wire is an oscillator harmonically oscillating one end of the wire at a frequency of 60 Hz, the other end of the wire runs over a pulley to a hanging mass that supplies the tension.What is the wavelength of the waves produced by the oscillator?

  • A piano wire with mass 3.45 g and length 75.0 cm is stretched with a tension...

    A piano wire with mass 3.45 g and length 75.0 cm is stretched with a tension of 25.0 N . A wave with frequency 100 Hz and amplitude 1.50 mm travels along the wire. Calculate the average power carried by the wave. What happens to the average power if the wave amplitude is halved?

  • A piano wire with mass 3.50 g and length 76.0 cm is stretched with a tension...

    A piano wire with mass 3.50 g and length 76.0 cm is stretched with a tension of 28.0 N. A wave with frequency 105 Hz and amplitude 1.70 mm travels along the wire. a.  Calculate the average power carried by the wave. Express your answer in watts. b.  What happens to the average power if the wave amplitude is halved? Express your answer in watts.

  • A piano wire with mass 2.95 g and length 76.0 cm is stretched with a tension...

    A piano wire with mass 2.95 g and length 76.0 cm is stretched with a tension of 29.0 N. A wave with frequency 105 Hz and amplitude 1.50 mm travels along the wire. Part A Calculate the average power carried by the wave. Express your answer in watts. Part B What happens to the average power if the wave amplitude is halved? Express your answer in watts.

  • P4. An aluminum wire of diameter 1.00 mm is put under a tension of 375 N....

    P4. An aluminum wire of diameter 1.00 mm is put under a tension of 375 N. If a 440. Hz driving force sets up a wave that propagates along this wire, calculate the wavelength.

  • How long must a 0.52-mm-diameter aluminum wire be to have a 0.58 A current when connected...

    How long must a 0.52-mm-diameter aluminum wire be to have a 0.58 A current when connected to the terminals of a 1.5 V flashlight battery?

  • a. In the figure below, a string is tied to a sinusoidal oscillator at P and...

    a. In the figure below, a string is tied to a sinusoidal oscillator at P and runs over a rigid support at Q, and is stretched by a block of mass m. The separation L - 1.77 m, the linear mu = 16 g/m, and the oscillator frequency f = 125 Hz. The amplitude of the motion at P is small enough for that point to be considered a node. A node also exists at Q. If m = 2.000...

  • spring-2010 5. (a) A steel wire of diameter 0.60 mm and length 1.5 m. support A...

    spring-2010 5. (a) A steel wire of diameter 0.60 mm and length 1.5 m. support A 5.0-kg mass. How much will the wire stretch under this load??Ystee-2x 1011 N/m2]

  • Q. A steel wire with mass 37.0 g and length 7.10 m is stretched tightly between...

    Q. A steel wire with mass 37.0 g and length 7.10 m is stretched tightly between its two endpoints. In its fundamental mode, the wire vibrates at a frequency of 59.0 Hz. When plucked, traveling waves bounce from one end to the other. a) What is the speed of waves propagating along the wire? b) Calculate the tension in the wire. c) A standing wave at the fundamental frequency has an amplitude of 0.340 cm . Calculate the magnitude of...

  • Part A How long must a 0.52-mm-diameter aluminum wire be to have a 0.58 A current when connected ...

    Part A How long must a 0.52-mm-diameter aluminum wire be to have a 0.58 A current when connected to the terminals of a 1.5 V flashlight battery? Express your answer to two significant figures and include the appropriate units. L= 1 Value Units Request Answer Submit Part B What is the current if the wire is half this length? Express your answer to two significant figures and include the appropriate units. I-Value Units SubmitRequest Answer Part A How long must...
