A 60 kg sofa 4 m long is carried by James and Sarah. James has the end, Sarah is holding the sofa at the other end. A passing moron places a 30 kg box of books on the sofa 0.5 m from the end of the sofa James is holding. How much weight is Sarah holding now? A) 331 N B) 352 N C) 398 N D) 460 N
A 60 kg sofa 4 m long is carried by James and Sarah. James has the...
can someone give me the reasoning behind this.
specifically the equations.
2 2. A 60 kg sofa 4m long is carried by James and Sarah. James is holding the sofa 0.2 m from an end. Sarah is holding the sofa by the other end. A passing moron places a 40 kg box of books on the sofa 0.5 m from the end Sarah is holding How much weight is Sarah holding now? a) 590 N b)610 N C) 620 N...
torque rotational equilibrium
2. A 10 kg cat walks along a 3 m long plank with a mass of 4 kg that is supported by two sawhorses. The right sawhorse is 0.7 m from the end of the plank. How far from the end of the right sawhorse can she walk before tipping the plank over. 3. Nintendo has designed a new minigame for the next Sonic Party. In the game, players have to balance a rigid body. Where should...
Jack and Jill are in a boat 4 m long. The boat has mass 48 kg and its weight is uniformly distributed along its length. Jill (mass 30 kg) sits at one end and Jack (mass 45 kg) sits at the other end. The boat is in still water, not moving as children stay still. If Jack and Jill exchange their positions, by how much does the boat move? Ignore any resistance of the lake's water.
A 2.18-m-long diving board of mass 13.2 kg is 3.00 m above the water. It has two attachments holding it in place. One is located at the very back end of the board, and the other is 25.0 cm away from that end. (a) Assuming that the board has uniform density, find the force acting on each attachment. {435 N, upward, 565 N, downward} b) If a diver of mass 69.3 kg is standing on the front end, what are...
1. A 10 kg, 2 m long board is placed on two supports. One is at the left end the other is 1.5 m to the right of the first. You have two boxes. One with a mass of 2.0 kg, and one with a mass of 4.0 kg. A. If the 2 kg box is 0.5 m from the left end and the 4 kg box is at the right end, what is the location of the center of...
3. A 4 m-long canoe will hold 3 campers. A 40 kg camper sits 0.5 m from one end of the canoe and a 30 kg camper sits 1.5 m from the other end of the canoe. Where should another 30 kg camper sit so that the center of mass is at the middle of the canoe? Drawing a diagram may be helpful. A. 1.0 m from the end closer to the 40 kg camper B. in the middle of...
14m pivot T 10m A 60-kg woman stands on the far right end of a 14-m-long uniform board. The support pillars are 10 m apart, and she is 2m from the right pillar. The board just barely starts to rotate clockwise, with the top of the right pillar as the pivot point. How much does the board weigh? 24 N O84 N 168 N 0235 N 0 1470 N
A nasty person puts a man m=60 kg into a cart m=100 kg, and
places the cart against a large spring with k=9000 N/m, compresses
the spring by d=1.75 m, then releases the cart. The man and cart
shoot down a horizontal track with coefficient of friction 0.10.
The track ends at the edge of an extremely deep abyss which is 4.0
m wide. The other side of the abyss is higher than the side of the
track by 5.0...
A 1500 kg truck 6.0 m long has the center of mass 0.75 m from the front. If two 100 kg men stand on the rear bumper, what is the weight on the rear wheels? (wheels 1.0 m from each end) A) 1370 N B) 1530 N C) 1720 N D) 1840 N
12. A 3.0 m long and 2.0 m wide carton of mass 100 kg leans against a smooth wall as shown in the figure The coefficient of state friction between the floor and the lower end of the carton is 0.80. The normal for the a 240 N h TOON c. 980 N d. 80N e. None of the above A 2.0 m long, 200 N uniformladder, rests with one end against a smooth wall making an angle of 30...
