Question

Phosgene (carbonyl chloride), COCl2, is an extremely toxic gas that is used in manufacturing certain dyes and plastics. Phosgene can be produced by reacting carbon monoxide and chlorine gas at high temperatures: CO(g)+Cl2(g)⇌COCl2(g) Carbon monoxide and chlorine gas are allowed to react in a sealed vessel at 453 ∘C . At equilibrium, the concentrations were measured and the following results obtained: Gas Partial Pressure (atm) CO 0.760 Cl2 1.23 COCl2 0.180 What is the equilibrium constant, Kp, of this reaction? Express your answer numerically. View Available Hint(s) Kp = Previous Answers Incorrect; Try Again Enclose complex terms in the denominator of a calculation in parentheses to ensure the correct order of mathematical precedence. You may need to review Order of Operations for Mathematical Expressions. Deriving concentrations from data In Part A, you were given the equilibrium pressures, which could be plugged directly into the formula for K. In Part B however, you will be given initial concentrations and only one equilibrium concentration. You must use this data to find all three equilibrium concentrations before you can apply the formula for K. Part B The following reaction was performed in a sealed vessel at 757 ∘C : H2(g)+I2(g)⇌2HI(g) Initially, only H2 and I2 were present at concentrations of [H2]=3.05M and [I2]=3.00M . The equilibrium concentration of I2 is 0.0200 M . What is the equilibrium constant, Kc, for the reaction at this temperature?

Answer 1
