An object is cut from a uniform block of wood, 3.00 cm thick, so that the...
An object is cut from a uniform block of wood, 3.00 cm thick, so that the height of the top edg e is described by the equation y=19(x-3)2. The left side of the object is 1.00 m tall, and it extends to 3.00 m long. The left side is placed on the y-axis and the bottom side is placed on the x-axis. Find (a) the x-coordinate and (b) the y-coordinate of its center of gravity
answer :
(a) 0.750 m
(b) 0.300 m
