An elevator (mass 4750 kg ) is to be designed so that the maximum acceleration is...

Question

Question

An elevator (mass 4750 kg ) is to be designed so that the maximum acceleration is 0.0660 g .

What is the maximum force the motor should exert on the supporting cable?

What is the minimum force the motor should exert on the supporting cable?

science physics

Answer 1

Answer #1

Answer 2
