the 12 gauge copper wire in a typical residential building has a cross-sectional area of 3.31e-6...
the 12 gauge copper wire in a typical residential building has a cross-sectional area of 3.31e-6 m^2. it carries a constant current of 10 A. What is the drift speed of the electrons in the wire? Assume each copper atom contributes one free electron to the current. The density of copper is 8.92 g/cm^3
Homework Answers
Add Answer to:
the 12 gauge copper wire in a typical residential building has a
cross-sectional area of 3.31e-6...
2. A copper wire carrying a current of 5.00 A has a cross-sectional area of 5.00...
2. A copper wire carrying a current of 5.00 A has a cross-sectional area of 5.00 x 106 m2. Find the drift speed of the electrons in the wire. The density of copper is 8.96 g/cm3. (Assume that each copper atom supplies one free electron.)
The maximum rated current for a copper wire of cross-sectional area 2 mm^2 is 20A. (a)...
The maximum rated current for a copper wire of cross-sectional
area 2 mm^2 is 20A. (a) What is the corresponding current density
in A/m^2? (b) On the assumption that each copper atom contributes
one conduction electron, calculate the electronic drift velocity
corresponding to this current density. (Avogadro's number =
6.02E10^23 atoms per mole; atomic weight of copper = 63.5; density
of copper = 8.92 g/cm^3.) (c) Use the observed conductivity to
calculate the average collision time for an electron in...
An aluminum wire having a cross-sectional area of 2.50 ✕ 10−6 m2 carries a current of...
An aluminum wire having a cross-sectional area of 2.50 ✕ 10−6 m2 carries a current of 3.00 A. The density of aluminum is 2.70 g/cm3. Assume each aluminum atom supplies one conduction electron per atom. Find the drift speed of the electrons in the wire.
An aluminum wire having a cross-sectional area of 4.70 ✕ 10−6 m2 carries a current of...
An aluminum wire having a cross-sectional area of 4.70 ✕ 10−6 m2 carries a current of 4.50 A. The density of aluminum is 2.70 g/cm3. Assume each aluminum atom supplies one conduction electron per atom. Find the drift speed of the electrons in the wire. mm/s
An aluminum wire having a cross-sectional area of 6.00 ✕ 10-6 m2 carries a current of...
An aluminum wire having a cross-sectional area of 6.00 ✕ 10-6 m2 carries a current of 8.00 A. Find the drift speed of the electrons in the wire. The density of aluminum is 2.70 g/cm3. Assume each aluminum atom supplies one conduction electron. mm/s
An aluminum wire having a cross-sectional area equal to 4.90 10-6 m2 carries a current of 4.00...
An aluminum wire having a cross-sectional area equal to 4.90 10-6 m2 carries a current of 4.00 A. The density of aluminum is 2.70 g/cm3. Assume each aluminum atom supplies one conduction electron per atom. Find the drift speed of the electrons in the wire.
Tipler6 25.P.031.soln. A 10 gauge copper wire carries a current of 23 A. Assuming one free...
Tipler6 25.P.031.soln. A 10 gauge copper wire carries a current of 23 A. Assuming one free electron per copper atom, calculate the drift velocity of the electrons. (The cross-sectional area of a 10-gauge wire is 5.261 mm2.) mm/s
A copper wire of 1.0 cross-sectional area carries a current of 2.72 A What is the...
A copper wire of 1.0 cross-sectional area carries a current of 2.72 A What is the magnitude of the drift velocity in m/s) for an electron in the wire? The number of free charge carries of copper per unit volume is 8.0x10 electrons/m! A. 2.0E10+
Tipler6 25.P.033.soln. A 10-gauge copper wire and a 14-gauge copper wire are welded together end to...
Tipler6 25.P.033.soln. A 10-gauge copper wire and a 14-gauge copper wire are welded together end to end. The wires carry a current of 15.8 A. (a) If there is one free electron per copper atom in each wire, find the drift velocity of the electrons in each wire. (Let the cross-sectional area of 10-gauge and 14-gauge wire be 5.261 mm2 and 2.081 mm2, respectively.) 10 - Gauge Wire _________ mm/s 14 - Gauge Wire _________ mm/s (b) What is the...
Tipler6 25.P.033.soln. A 10-gauge copper wire and a 14-gauge copper wire are welded together end to...
Tipler6 25.P.033.soln. A 10-gauge copper wire and a 14-gauge copper wire are welded together end to end. The wires carry a current of 15.8 A. (a) If there is one free electron per copper atom in each wire, find the drift velocity of the electrons in each wire. (Let the cross-sectional area of 10-gauge and 14-gauge wire be 5.261 mm2 and 2.081 mm2, respectively.) 10-gauge wire mm/s 14-gauge wire mm/s (b) What is the ratio of the magnitude of the...
2. A copper wire carrying a current of 5.00 A has a cross-sectional area of 5.00 x 106 m2. Find the drift speed of the electrons in the wire. The density of copper is 8.96 g/cm3. (Assume that each copper atom supplies one free electron.)
The maximum rated current for a copper wire of cross-sectional
area 2 mm^2 is 20A. (a) What is the corresponding current density
in A/m^2? (b) On the assumption that each copper atom contributes
one conduction electron, calculate the electronic drift velocity
corresponding to this current density. (Avogadro's number =
6.02E10^23 atoms per mole; atomic weight of copper = 63.5; density
of copper = 8.92 g/cm^3.) (c) Use the observed conductivity to
calculate the average collision time for an electron in...
A copper wire of 1.0 cross-sectional area carries a current of 2.72 A What is the magnitude of the drift velocity in m/s) for an electron in the wire? The number of free charge carries of copper per unit volume is 8.0x10 electrons/m! A. 2.0E10+
