A solid pulley with mass of 25 kg and radius 5 cm cxan rotate about an...

A solid pulley with mass of 25 kg and radius 5 cm cxan rotate about an axis through its. what is angular accelearation of the pulley if a string wrapped around the circumference the pulley is pulled with force 12N

1/ 8.3 rad

2/11.6 rad

3/19.2 rad

4/ 15.9 rad

5/ 23.6 rad

science   physics
0 0
Add a comment Improve this question Transcribed image text
Next > < Previous
Sort answers by oldest

Homework Answers

Answer #1


0 0
Add a comment
