A ball with an x amount of lbs moving horizontally with a velocity of ft/s strikes...
A ball with an x amount of lbs moving horizontally with a velocity of ft/s strikes a block with a mass of x lbs. The coefficient of static and friction between the block and the ramp is mu(s)= mu(k)= .35 and the coefficient of restitution between the ball and block is e =.70. Determine the distance the block slides up the ramp before stopping.
How do I set this up equation wise? FBD? What equations are used? please don't skip steps. gravity is 32.2 ft/s^2
Homework Answers
Add Answer to:
A ball with an x amount of lbs moving horizontally with a
velocity of ft/s strikes...
7 of 7 A 3-lb ball A is traveling horizontally at 18 ft/s when it strikes...
7 of 7 A 3-lb ball A is traveling horizontally at 18 ft/s when it strikes a 14-lb block B that is at rest. Rev Part A If the efficient of restitution between A and B ise 0.6, and the coefficient of kinetic friction between the plane and the block is 0.2, determine the time for the block B to stop sliding Express your answer using three significant figures and include the appropriate units. H ? 10.307 S Submit Previous...
Question 2 (20 marks): A 1 kg ball A is traveling horizontally at 20 m/s when...
Question 2 (20 marks): A 1 kg ball A is traveling horizontally at 20 m/s when it strikes a 10 kg block B that is at rest. If the coefficient of restitution between A and B is e = 0.6, and the coefficient of kinetic friction between the plane and the block is uy = 0.4, determine: 1. speed of the ball and block after the collision 2. the time for the block to stop sliding 3. the distance the...
A 0.0260 kg bullet moving horizontally at 450 m/s embeds itself into an initially stationary 0.500...
A 0.0260 kg bullet moving horizontally at 450 m/s embeds itself into an initially stationary 0.500 kg block (a) What is their velocity just after the collision? m/s (b) The bullet-embedded block slides 8.0 m on a horizontal surface with a 0.30 kinetic coefficient of friction. Now what is its velocity? my's (c) The bullet embedded block now strikes and sticks to a stationary 2.00 kg block. How far does this combination travel before stopping? חח Additional Materials Reading
A0.0240 kg bullet moving horizontally at 500 m/s embeds itself into an initially stationary 0.500 kg...
A0.0240 kg bullet moving horizontally at 500 m/s embeds itself into an initially stationary 0.500 kg block (a) What is their velocity (in m/s) just after the collision? m/s (b) The bulet-embedded biock slides 8.0 m on a horizontal surface with a 0.30 kinetic coefficient of friction, Now what is its velocity (in m/s)? m/s (c) The bullet-embedded block now strikes and sticks to a stationary 2.00 kg block. How far (in m) does this combination travel before stopping? m
Vi = 8 ft/s 3 ft The girl throws the ball with a horizontal velocity of...
Vi = 8 ft/s 3 ft The girl throws the ball with a horizontal velocity of v, = 8 ft/s. If the coefficient of restitution between the ball and the ground is e = 0.8. determine the velocity of the ball just after it rebounds from the ground and the maximum height to which the ball rises after the first bounce.
A person kicks a ball, giving it an initial velocity of 20.0 m/s up a wooden...
A person kicks a ball, giving it an initial velocity of 20.0 m/s up a wooden ramp. When the ball reaches the top, it becomes airborne. The ramp makes an angle of 22.0º to the ground, and the ball travels a distance of 5.00 m on the ramp. What is the maximum height the ball reaches, above the point where it was kicked, if (a) the ramp is frictionless and (b) there is a coefficient of friction of 0.150 between...
A 0.03-Ib bullet traveling at 1300 ft/s strikes the 10.4-lb wooden block and exits the other...
A 0.03-Ib bullet traveling at 1300 ft/s strikes the 10.4-lb wooden block and exits the other side at 50 ft/sas shown. The coefficient of kinetic friction between the block and the surface is 0.5 (Figure 1) Part A Figure Determine the speed of the block just after the bullet exits the block Express your answer to three significant figures and include the appropriate units. 1 of 1 > HAO 21 ? Value Units 5 1300 50%, Submit Previous Answers Rest...
can you please help with part C thanks! A 0.0230 kg bullet moving horizontally at 450...
can you please help with part C thanks!
A 0.0230 kg bullet moving horizontally at 450 m/s embeds itself into an initially stationary 0.500 kg block. (a) What is their velocity (in m/s) just after the collision? 19.79 (b) The bullet-embedded block slides 8.0 m on a horizontal surface with a 0.30 kinetic coefficient of friction. Now what is its velocity (in m/s)? 18.56 (c) The bullet-embedded block now strikes and sticks to a stationary 2.00 kg block. How far...
A 0.03-lb bullet traveling at 1300 ft/s strikes the 12-lb wooden block and exits the other...
A 0.03-lb bullet traveling at 1300 ft/s strikes the 12-lb wooden block and exits the other side at 50 ft/s as shown. The coefficient of kinetic friction between the block and the surface is 0.5. (Figufe 1) Part A Determine the speed of the block just after the bullet exits the block. Express your answer to three significant figures and include the appropriate units. Units Submit Request Answer Part B Determine how far the block slides before it stops. Express...
Ball has initial velocity v m/s in x direction Cliff Ball strikes sea at point (s,0)...
Ball has initial velocity v m/s in x direction Cliff Ball strikes sea at point (s,0) Sea (0,0) 3(c) [7 Marks] A golf ball is struck with velocityv (meters per second) from the edge of a cliff which rises h metres above sea level. Referring to figure (3) the golf ball starts at the point (0, h) follows a parabola and strikes the sea some time later at the point (8,0). It can be shown that the (x, y) location...
7 of 7 A 3-lb ball A is traveling horizontally at 18 ft/s when it strikes a 14-lb block B that is at rest. Rev Part A If the efficient of restitution between A and B ise 0.6, and the coefficient of kinetic friction between the plane and the block is 0.2, determine the time for the block B to stop sliding Express your answer using three significant figures and include the appropriate units. H ? 10.307 S Submit Previous...
Question 2 (20 marks): A 1 kg ball A is traveling horizontally at 20 m/s when it strikes a 10 kg block B that is at rest. If the coefficient of restitution between A and B is e = 0.6, and the coefficient of kinetic friction between the plane and the block is uy = 0.4, determine: 1. speed of the ball and block after the collision 2. the time for the block to stop sliding 3. the distance the...
A 0.0260 kg bullet moving horizontally at 450 m/s embeds itself into an initially stationary 0.500 kg block (a) What is their velocity just after the collision? m/s (b) The bullet-embedded block slides 8.0 m on a horizontal surface with a 0.30 kinetic coefficient of friction. Now what is its velocity? my's (c) The bullet embedded block now strikes and sticks to a stationary 2.00 kg block. How far does this combination travel before stopping? חח Additional Materials Reading
A0.0240 kg bullet moving horizontally at 500 m/s embeds itself into an initially stationary 0.500 kg block (a) What is their velocity (in m/s) just after the collision? m/s (b) The bulet-embedded biock slides 8.0 m on a horizontal surface with a 0.30 kinetic coefficient of friction, Now what is its velocity (in m/s)? m/s (c) The bullet-embedded block now strikes and sticks to a stationary 2.00 kg block. How far (in m) does this combination travel before stopping? m
Vi = 8 ft/s 3 ft The girl throws the ball with a horizontal velocity of v, = 8 ft/s. If the coefficient of restitution between the ball and the ground is e = 0.8. determine the velocity of the ball just after it rebounds from the ground and the maximum height to which the ball rises after the first bounce.
A 0.03-Ib bullet traveling at 1300 ft/s strikes the 10.4-lb wooden block and exits the other side at 50 ft/sas shown. The coefficient of kinetic friction between the block and the surface is 0.5 (Figure 1) Part A Figure Determine the speed of the block just after the bullet exits the block Express your answer to three significant figures and include the appropriate units. 1 of 1 > HAO 21 ? Value Units 5 1300 50%, Submit Previous Answers Rest...
can you please help with part C thanks!
A 0.0230 kg bullet moving horizontally at 450 m/s embeds itself into an initially stationary 0.500 kg block. (a) What is their velocity (in m/s) just after the collision? 19.79 (b) The bullet-embedded block slides 8.0 m on a horizontal surface with a 0.30 kinetic coefficient of friction. Now what is its velocity (in m/s)? 18.56 (c) The bullet-embedded block now strikes and sticks to a stationary 2.00 kg block. How far...
A 0.03-lb bullet traveling at 1300 ft/s strikes the 12-lb wooden block and exits the other side at 50 ft/s as shown. The coefficient of kinetic friction between the block and the surface is 0.5. (Figufe 1) Part A Determine the speed of the block just after the bullet exits the block. Express your answer to three significant figures and include the appropriate units. Units Submit Request Answer Part B Determine how far the block slides before it stops. Express...
Ball has initial velocity v m/s in x direction Cliff Ball strikes sea at point (s,0) Sea (0,0) 3(c) [7 Marks] A golf ball is struck with velocityv (meters per second) from the edge of a cliff which rises h metres above sea level. Referring to figure (3) the golf ball starts at the point (0, h) follows a parabola and strikes the sea some time later at the point (8,0). It can be shown that the (x, y) location...
