What frequencies (in Hz) will a 1.75 m long tube produce in the audible range (20...

What frequencies (in Hz) will a 1.75 m long tube produce in the audible range (20 Hz - 20,000 Hz) at 25.0°C for the following cases?

a) the tube is closed at one end lowest frequency

second lowest frequency

highest frequency

b) the tube is open at both ends

lowest frequency Hz

second lowest frequency Hz

highest frequency

science   physics
0 0
Add a comment Improve this question Transcribed image text
Next > < Previous
Sort answers by oldest

Homework Answers

Answer #1

0 0
Add a comment
Know the answer?
Add Answer to:
What frequencies (in Hz) will a 1.75 m long tube produce in the audible range (20...
Your Answer:

Post as a guest

Your Name:

What's your source?

Earn Coins

Coins can be redeemed for fabulous gifts.

Log In

Sign Up

Not the answer you're looking for? Ask your own homework help question. Our experts will answer your question WITHIN MINUTES for Free.
Similar Homework Help Questions

  • What frequencies (in Hz) will a 1.90 m long tube produce in the audible range (20...

    What frequencies (in Hz) will a 1.90 m long tube produce in the audible range (20 Hz - 20,000 Hz) at 18.0°C for the following cases? (a) the tube is closed at one end Hz Hz Hz lowest frequency second lowest frequency highest frequency (rounded to the nearest Hz) (b) the tube is open at both ends Hz Hz Hz lowest frequency second lowest frequency highest frequency (rounded to the nearest Hz)

  • What frequencies will a 1.65 m long tube produce in the audible range (20 Hz -...

    What frequencies will a 1.65 m long tube produce in the audible range (20 Hz - 20,000 Hz) at 17.0°C for the following cases? (a) the tube is closed at one end lowest frequency Hz second lowest frequency Hz highest frequency (rounded to the nearest Hz) Hz (b) the tube is open at both ends lowest frequency Hz second lowest frequency Hz highest frequency (rounded to the nearest Hz) Hz

  • You have two air columns that are each 2.130 m long. One column is open at...

    You have two air columns that are each 2.130 m long. One column is open at both ends and the other is closed at one end. You wish to determine the frequencies you can produce in the audible range (20 Hz–20,000 Hz) on a day when the temperature of the air is at 22.00°C. (Give your answers to at least four significant figures. Assume that the speed of sound at 0° C is exactly 331 m/s.) (a)  in the column that...

  • A 2.39-m long organ pipe acts as a closed-end resonator that produces several different harmonic frequencies...

    A 2.39-m long organ pipe acts as a closed-end resonator that produces several different harmonic frequencies in the audible range from 20 Hz to 20,000 Hz. Assuming the speed of sound is 343 m/s, determine the 5th highest frequency that the pipe can produce.

  • An engineer measures the frequencies of the audible standing waves in an organ pipe. He finds...

    An engineer measures the frequencies of the audible standing waves in an organ pipe. He finds two adjacent tones at 420 and 540 Hz. (a) On the basis of this discovery, the engineer computes the pipe's fundamental frequency. What is its value (in Hz)? Hz (b) Is the pipe open at both ends or only one? open at both ends open at only one end (c) The air within the pipe has a temperature of 20°C and is at atmospheric...

  • SOLUTION (A) Find the frequencies if the pipe is open at both ends. _V 343 m/s...

    SOLUTION (A) Find the frequencies if the pipe is open at both ends. _V 343 m/s Substitute into whole harmonics equation, with n = 1. 11-222(2.46 m) = 69.7 Hz Multiply to find the second and third harmonics. 12 - 27 - 139 Hz 13 = 3f7 - 209 Hz (B) How many harmonics lle between 20 Hz and 20000 Hz for this pipe? 343 m/s Set the frequency in the harmonics equation equal to 2.00 x 104 Hz and...

  • One of the harmonic frequencies of tube A with two open ends is 710 Hz. The...

    One of the harmonic frequencies of tube A with two open ends is 710 Hz. The next-highest harmonic frequency is 781 Hz. (a) What harmonic frequency is next highest after the harmonic frequency 355 Hz? (b) What is the number of this next-highest harmonic? One of the harmonic frequencies of tube B with only one open end is 4847 Hz. The next-highest harmonic frequency is 5109 Hz. (c) What harmonic frequency is next highest after the harmonic frequency 2489 Hz?...

  • If the fundamental frequency of a tube is 840 Hz, and the speed of sound is...

    If the fundamental frequency of a tube is 840 Hz, and the speed of sound is 343 m/s, determine the length of the tube (in m) for each of the following cases. If the fundamental frequency of a tube is 840 Hz, and the speed of sound is 343 m/s, determine the length of the tube (in m) for each of the following cases. (a) the tube is closed at one end m (b) the tube is open at both...

  • Problem 3: A certain pipe has resonant frequencies of 234 Hz, 390 Hz, and 546 Hz,...

    Problem 3: A certain pipe has resonant frequencies of 234 Hz, 390 Hz, and 546 Hz, with no other resonant frequencies between these values. (Hint: The lower frequency is not necessarily the pipe fundamental frequency) (a) Show that the difference of frequency between two adjacent harmonics has the same expression for a pipe open at both ends as for a pipe closed at one end (b) How long is this pipe? (c) Is this a pipe open at both ends...

  • If the fundamental frequency of tube is 671 HZ, and the speed of sound is 343...

    If the fundamental frequency of tube is 671 HZ, and the speed of sound is 343 mys, determine the length of the tube (in m) for each of the following cases. (a) the tube is closed at one end (b) the tube is open at both ends Need Help? Read
