A bullet of mass 20 g is fired into a ballistic pendulum of mass 5 kg....
A bullet of mass 20 g is fired into a ballistic pendulum of mass 5 kg. The center of gravity of the pendulum rises 10 cm after being struck. Find the initial velocity of the bullet.
Homework Answers
Add Answer to:
A bullet of mass 20 g is fired into a ballistic pendulum of mass
5 kg....
A bullet of mass 4.5 g strikes a ballistic pendulum of mass 1.7 kg. The center...
A bullet of mass 4.5 g strikes a ballistic pendulum of mass 1.7 kg. The center of mass of the pendulum rises a vertical distance of 6.3 cm. Assuming that the bullet remains embedded in the pendulum, calculate the bullet's initial speed.
A bullet of mass 3.1 g strikes a ballistic pendulum of mass 2.7 kg. The center...
A bullet of mass 3.1 g strikes a ballistic pendulum of mass 2.7 kg. The center of mass of the pendulum rises a vertical distance of 6.1 cm. Assuming that the bullet remains embedded in the pendulum, calculate the bullet's initial speed.
A bullet of mass 2.9 g strikes a ballistic pendulum of mass 4.7 kg. The center...
A bullet of mass 2.9 g strikes a ballistic pendulum of mass 4.7 kg. The center of mass of the pendulum rises a vertical distance of 15 cm. Assuming that the bullet remains embedded in the pendulum, calculate the bullet's initial speed.
A bullet of mass 8 g is fired into a 1.2 kg ballistic pendulum (a block...
A bullet of mass 8 g is fired into a 1.2 kg ballistic pendulum (a block of wood acting as the pendulum bob of a thin metal arm attached to a low friction pivot point) that is initially at rest. The bullet exits the block of wood with a speed of 180 m/s and the wooden block swings from its lowest point to a maximum height of 9.2 cm above that location. Determine the velocity of the bullet before it...
A bullet of mass 10 g is fired horizontally into a block of wood of mass...
A bullet of mass 10 g is fired horizontally into a block of wood of mass 2 kg and suspended like a ballistic pendulum. The bullet sticks in the block and the impact causes the block to swing so that its center of gravity rises 0.1 m. Find the velocity of the bullet just before the impact. Can someone also explain the steps to me? I am very confused on all of this. Thank you
A bullet of mass 3.3 g strikes a ballistic pendulum of mass 1.3kg. The center of...
A bullet of mass 3.3 g strikes a ballistic pendulum of mass 1.3kg. The center of mass of the pendulum rises a vertical distance of6.6 cm. Assuming that the bullet remains embedded in the pendulum,calculate the bullet's initial speed.
A 10.0 g rifle bullet is fired with a speed of 370 m/s into a ballistic...
A 10.0 g rifle bullet is fired with a speed of 370 m/s into a ballistic pendulum with mass 7.00 kg , suspended from a cord 70.0 cm long. A) Compute the initial kinetic energy of the bullet; B) Compute the kinetic energy of the bullet and pendulum immediately after the bullet becomes embedded in the pendulum. C) Compute the vertical height through which the pendulum rises.
A ballistic pendulum is used to measure the speed of bullets. In these experiments, a bullet...
A ballistic pendulum is used to measure the speed of bullets. In these experiments, a bullet is fired into a large block suspended by wires. The bullet is embedded in the block and the collision is inelastic. After the impact, the block swings forward and rises. a. If a 2.1-g bullet is fired at 440 m/s into a 4.0 kg block, how far will it swing up? (what is the maximum vertical displacement of the block?) b. Find an equation...
1. A 35 g bullet is fired into the bob of a ballistic pendulum of mass...
1. A 35 g bullet is fired into the bob of a ballistic pendulum of mass 4.75 kg. When the bob is at its maximum height, the string makes an angle of 55 with the vertical. The length of the pendulum is 4.0 m. Find the speed of the bullet before impact. (Hint: Consider Momentum and Energy Conservation)
In a ballistic pendulum an object of mass is fired with an initial speed at a pendulum bob. The bob has a mass, which...
In a ballistic pendulum, an object of mass m is fired with an initial speed v0 at a pendulum bob. The bob has a mass M, which is suspended by a rod of length L and negligible mass. After the collision, the pendulum and
object stick together and swing to a maximum angular displacement θ as shown.A. Find an expression for v0, the initial speed of the fired object.Express your answer in terms of some or all of the variables m, M, L, and...
A bullet of mass 8 g is fired into a 1.2 kg ballistic pendulum (a block of wood acting as the pendulum bob of a thin metal arm attached to a low friction pivot point) that is initially at rest. The bullet exits the block of wood with a speed of 180 m/s and the wooden block swings from its lowest point to a maximum height of 9.2 cm above that location. Determine the velocity of the bullet before it...
1. A 35 g bullet is fired into the bob of a ballistic pendulum of mass 4.75 kg. When the bob is at its maximum height, the string makes an angle of 55 with the vertical. The length of the pendulum is 4.0 m. Find the speed of the bullet before impact. (Hint: Consider Momentum and Energy Conservation)
In a ballistic pendulum, an object of mass m is fired with an initial speed v0 at a pendulum bob. The bob has a mass M, which is suspended by a rod of length L and negligible mass. After the collision, the pendulum and
object stick together and swing to a maximum angular displacement θ as shown.A. Find an expression for v0, the initial speed of the fired object.Express your answer in terms of some or all of the variables m, M, L, and...
