(a) What is the voltage output (in V) of a transformer used for rechargeable flashlight batteries,...



(a)

What is the voltage output (in V) of a transformer used for rechargeable flashlight batteries, if its primary has 490 turns, its secondary 8 turns, and the input voltage is 122 V?

(b)
What input current (in mA) is required to produce a 4.00 A output?
(c)
What is the power input (in W)?

science   physics
0 0
Add a comment Improve this question Transcribed image text
Next > < Previous
Sort answers by oldest

Homework Answers

Answer #1

0 0
Add a comment
Know the answer?
Add Answer to:
(a) What is the voltage output (in V) of a transformer used for rechargeable flashlight batteries,...
Your Answer:

Post as a guest

Your Name:

What's your source?

Earn Coins

Coins can be redeemed for fabulous gifts.

Log In

Sign Up

Not the answer you're looking for? Ask your own homework help question. Our experts will answer your question WITHIN MINUTES for Free.
Similar Homework Help Questions

  • A step-down transformer is used for a rechargeable phone. a. What is the voltage output of...

    A step-down transformer is used for a rechargeable phone. a. What is the voltage output of a transformer used for rechargeable flashlight batteries, if its primary has 400 turns, its secondary 2.5 turns, and the input voltage is 110 V? b. What input current is required to produce a 0.50 A output? c. What is the power input?

  • Suppose a motor connected to a 135 V source draws 21.5 A when it first starts....

    Suppose a motor connected to a 135 V source draws 21.5 A when it first starts. (a) What is its resistance (in Ω)? Answer in Ω. (b) What current (in A) does it draw at its normal operating speed when it develops a 100 V back emf? Answer in A. (c) What is the voltage output (in V) of a transformer used for rechargeable flashlight batteries, if its primary has 525 turns, its secondary 8 turns, and the input voltage...

  • A step-down transformer with 500 primary turns and 15 secondary turns is used for a rechargeable...

    A step-down transformer with 500 primary turns and 15 secondary turns is used for a rechargeable device. The input voltage is 110V, while the output current is 0.25A. a. What is the voltage output, the current input, and the power (input or output)?

  • The rechargeable batteries for a laptop computer need a much smaller voltage than what a wall...

    The rechargeable batteries for a laptop computer need a much smaller voltage than what a wall socket provides. Therefore, a transformer is plugged into the wall socket and produces the necessary voltage for charging the batteries. The batteries are rated at 9.0 V, and a current of 187 mA is used to charge them. The wall socket provides a voltage of 120 V. (a) Determine the turns ratio of the transformer. (b) What is the current coming from the wall...

  • The rechargeable batteries for a laptop computer need a much smaller voltage than what a wall...

    The rechargeable batteries for a laptop computer need a much smaller voltage than what a wall socket provides. Therefore, a transformer is plugged into the wall socket and produces the necessary voltage for charging the batteries. The batteries are rated at 9.0 V, and a current of 194 mA is used to charge them. The wall socket provides a voltage of 120 V. (a) Determine the turns ratio of the transformer. Ns /Np (b) What is the current coming from...

  • Question 11 The rechargeable batteries for a laptop computer need a much smaller voltage than what...

    Question 11 The rechargeable batteries for a laptop computer need a much smaller voltage than what a wall socket provides. Therefore, a transformer is plugged into the wall socket and produces the necessary voltage for charging the batteries. The batteries are rated at 9.0V, and a current of 237 mA is used to charge them. The wall socket provides a voltage of 120 V.(a) Determine the turns ratio of the transformer. (b) What is the current coming from the wall...

  • The output rms voltage of a 480 W transformer is 240 V and the input rms...

    The output rms voltage of a 480 W transformer is 240 V and the input rms current is 0.4 A. The primary coil has 200 turns, how many turns does the secondary could have?

  • A step-down transformer is used for recharging the batteries of portable electronic devices. The turns ratio...

    A step-down transformer is used for recharging the batteries of portable electronic devices. The turns ratio N2/N1 for a particular transformer used in a DVD player is 1:10. When used with 120-V (rms) household service, the transformer draws an rms current of 38.0 mA from the house outlet. (a) Find the rms output voltage (in V) of the transformer. V (b) Find the power (in W) delivered to the DVD player. W (c) What If? What would be the current...

  • Will rate for answer with work! A step-down transformer is used for recharging the batteries of...

    Will rate for answer with work! A step-down transformer is used for recharging the batteries of portable devices. The turns ratio N2/N1 for a particular transformer used in a CD player is 3:46. When used with 120-V (rms) household service, the transformer draws an rms current of 100 mA. (a) Find the rms output voltage of the transformer. V (b) Find the power delivered to the CD player. W

  • MS TOUR TEACHER A step-down transformer is used for recharging the batteries of portable electronic devices....

    MS TOUR TEACHER A step-down transformer is used for recharging the batteries of portable electronic devices. The turns ratio N/N, for a particular transformer used in a DVD player is 1:15. When used with 120-V (rms) household service, the transformer draws an mms current of 23.5 mA from the house outlet (a) Find the rms output voltage (in V) of the transformer V (b) Find the power in W) delivered to the DVD player w (c) What If? What would...
