A rectangular loop with 200 turns and an area of 0.45 m^2 rotates in a 0.005...
A rectangular loop with 200 turns and an area of 0.45 m^2 rotates in a 0.005 T magnetic field at a frequency of 40 Hz. What is the maximum induced voltage in the loop?
Homework Answers
Add Answer to:
A rectangular loop with 200 turns and an area of 0.45 m^2
rotates in a 0.005...
2. A loop of N turns of area a rotates with angular velocity w normal to...
2. A loop of N turns of area a rotates with angular velocity w normal to a magnetic field B. At t=0 the plane of the loop is parallel to B, as shown. Find the induced emf. Find the maximum emf for N=17, a=10 cm, B=0.40T,f=60Hz. emf
7.) (a) A rectangular loop of area 0.1 m2 rotates in a uniform magnetic field of...
7.) (a) A rectangular loop of area 0.1 m2 rotates in a uniform magnetic field of B 2 T. When the angle between the magnetic field and the surface of the loop is 600 and increasing at 1 rad/s, what emf is induced in the loop? (b) The loop has turned further and has stopped with its surface parallel to the magnetic field. If the magnetic field then changes at the rate of 1 T/s, what emf is induced in...
2.) (a) A rectangular loop of area 0.15 m2 turns in a uniform magnetic field B-...
2.) (a) A rectangular loop of area 0.15 m2 turns in a uniform magnetic field B- 0.2 T. When the angle between the field and the normal to the loop is ?/2 radians and increasing at 0.6 rad/s, what emf is induced in the loop? (b) A current of 20 mA flows ina single circular loop of 2m circumference. A magnetic field of 1 T is directed parallel to the plane of the loop. What is the magnetic moment of...
A rectangular loop (area = 1.1 m2) turns in a uniform magnetic field, B = 2.6...
A rectangular loop (area = 1.1 m2) turns in a uniform magnetic field, B = 2.6 T. When the angle between the field and the normal to the plane of the loop is pi/2 rad and increasing at 2.1 rad/s, what emf is induced in the loop?
A rectangular coil of N turns with length a and width b rotates at frequency fin...
A rectangular coil of N turns with length a and width b rotates at frequency fin a uniform magnetic field B. The coil is connected to co- rotating cylinders, against which metal brushes slide to make contact. Calculate the mathematical expression of the induced voltage. Sliding contacts вх х х х х х х х х х г 1 * x * Answer: 0 = NB · À = NabBcos(21ft) = V = -N = 21f NabBsin(2nft) Can you design...
A rectangular loop (area = 0.250 m2) turns in a uniform magnetic field with B =...
A rectangular loop (area = 0.250 m2) turns in a uniform magnetic field with B = 0.210 T. At an instant when the angle between the magnetic field and the normal to the plane of the loop is π/2 rads and increasing at the rate of 0.530 rad/s, what is the magnitude of the emf induced in the loop? 9.91E–2 V 1.47E–2 V 2.78E–2 V 5.25E–2 V 0
Which letter is correct? 2. A rectangular loop (area 0.15 m2) turns in a uniform magnetic...
Which letter is correct?
2. A rectangular loop (area 0.15 m2) turns in a uniform magnetic field with B -0.20 T. At an instant when the angle between the magnetic field and the normal to the plane of the loop is d2 rads and increasing at the rate of 0.60 rad/s, what is the magnitude of the emf induced in the loop? a. Zero b. 30 mV c. 24 mV d. 18 mV
The coil in an AC generator consists of 6 turns of wire, each of area A=...
The coil in an AC generator consists of 6 turns of wire, each of area A= 0.0800 m², and the total resistance of the wire is 10.0 V. The coil rotates in a 0.400-T magnetic field at a constant frequency of 50.0 Hz. Find the maximum induced emf in the coil. What is the maximum induced current in the coil when the output terminals are connected to a low- resistance conductor?
Chapter 30, Problem 022 A rectangular loop (area 2.6 m2) turns in a uniform magnetic field,...
Chapter 30, Problem 022 A rectangular loop (area 2.6 m2) turns in a uniform magnetic field, B = 2.9 T. when the angle between the field and the normal to the plane of the loop is π / 2 what emf is induced in the loop? Number the tolerance is +/-596 rad and increasing at 3.7 rad/s, Units
An AC generator with armature loop area of 0.1 m2 and 20 turns, rotates the armature...
An AC generator with armature loop area of 0.1 m2 and 20 turns, rotates the armature at 60 Hz within a static magnetic field with magnetic flux density of 0.2 T. A) Using V_emf^m=NAωB_0 sinωt, include below the appropriate numeric expression for V_emf^m as a function of time including units. (Hint: The peak emf voltage should be between 140 and 160 V.) B) Using MATLAB, plot the V_emf^m expression derived for part (a.) for time t ranging from 0 to...
2. A loop of N turns of area a rotates with angular velocity w normal to a magnetic field B. At t=0 the plane of the loop is parallel to B, as shown. Find the induced emf. Find the maximum emf for N=17, a=10 cm, B=0.40T,f=60Hz. emf
7.) (a) A rectangular loop of area 0.1 m2 rotates in a uniform magnetic field of B 2 T. When the angle between the magnetic field and the surface of the loop is 600 and increasing at 1 rad/s, what emf is induced in the loop? (b) The loop has turned further and has stopped with its surface parallel to the magnetic field. If the magnetic field then changes at the rate of 1 T/s, what emf is induced in...
2.) (a) A rectangular loop of area 0.15 m2 turns in a uniform magnetic field B- 0.2 T. When the angle between the field and the normal to the loop is ?/2 radians and increasing at 0.6 rad/s, what emf is induced in the loop? (b) A current of 20 mA flows ina single circular loop of 2m circumference. A magnetic field of 1 T is directed parallel to the plane of the loop. What is the magnetic moment of...
A rectangular coil of N turns with length a and width b rotates at frequency fin a uniform magnetic field B. The coil is connected to co- rotating cylinders, against which metal brushes slide to make contact. Calculate the mathematical expression of the induced voltage. Sliding contacts вх х х х х х х х х х г 1 * x * Answer: 0 = NB · À = NabBcos(21ft) = V = -N = 21f NabBsin(2nft) Can you design...
Which letter is correct?
2. A rectangular loop (area 0.15 m2) turns in a uniform magnetic field with B -0.20 T. At an instant when the angle between the magnetic field and the normal to the plane of the loop is d2 rads and increasing at the rate of 0.60 rad/s, what is the magnitude of the emf induced in the loop? a. Zero b. 30 mV c. 24 mV d. 18 mV
The coil in an AC generator consists of 6 turns of wire, each of area A= 0.0800 m², and the total resistance of the wire is 10.0 V. The coil rotates in a 0.400-T magnetic field at a constant frequency of 50.0 Hz. Find the maximum induced emf in the coil. What is the maximum induced current in the coil when the output terminals are connected to a low- resistance conductor?
Chapter 30, Problem 022 A rectangular loop (area 2.6 m2) turns in a uniform magnetic field, B = 2.9 T. when the angle between the field and the normal to the plane of the loop is π / 2 what emf is induced in the loop? Number the tolerance is +/-596 rad and increasing at 3.7 rad/s, Units
