A pendulum made of a uniform rod with a length of 75 cm is set into...

A pendulum made of a uniform rod with a length of 75 cm is set into harmonic motion about one end. 1) Calculate the period of its motion. (Express your answer to two significant figures.)

science   physics
0 0
Add a comment Improve this question Transcribed image text
Next > < Previous
Sort answers by oldest

Homework Answers

Answer #1

I support mglum x T = 2A 0.75 9.8 3 T = 1.42 =1.42 sec

0 0
Add a comment
