A 3 kg block slides from the top of a 3.4 m high frictionless incline. At the bottom of the incline the block encounters a spring with a spring constant of 400 N/m on a horizontal surface. How far is the spring compressed? The correct answer is 0.71 meters but I need the worked out solution!
Spring 2019 Physics 309 Exam 2 Question 3 A block sits at the top of a 20 m hill. How fast will the block be once it reaches the bottom of the hill? sliding a. - 20(9.s) sin 30 Fsu : 20 (9.9 cos 30 Question 4 A block sits at the top of a 20 m high hill. It slides down the hill and then slides up a second hill whose height is 8 m. How fast will the...
A 15.0 kg stone slides down a snow-covered hill, leaving point A at a speed of 10.0 m/s. There is no friction on the hill between points A and B, but there is friction on the level ground at the bottom of the hill, between B and the wall. After entering the rough horizontal region, the stone travels 100 m and then runs into a very long, light spring with force constant 2.0 N/m. The coefficients of kinetic friction between...
1
3. A block of mass m 1.9 kg is held against a spring of spring constant k 410 and compressed 0.75 m. When released, it is pushed along the frictionless surface towards mi rebounds mass m 4.3 kg. The two masses collide and mass towards the spring at a speed of 2.1 m/s, while mass m slides back towards the spring at a sp a. What is the speed of mass mi right before the collision? b. What is...
A
4.00 kg block starts sliding from rest from the top of a
frictionless incline, the mass slides along a horizontal surface
and collides with a spring compressing it a distance x. The spring
will compress 3 meters with an applied force of 300N.
A) Calulate the speed of the block at the halfway down the
incline.
B) Calculate the speed of the block at the bottom of the
incline
C) How much work is done on the block by...
QUESTION 16 A 90 kg skier at the top of a 400 m icy hill slides down, through a 20 m patch of snow (uk-0.25) and hits a 20 m long jump ramp at a 45° incline. a) (10 points) How far from the edge of the ramp does the skier land (m)? 1400 m 20 m 45° 20 m b) (5 points) How high will he get of the ground (max height (m)) ?
A 2.00-kg block starts sliding from the top of a frictionless incline. At the bottom of the incline, the mass slides along a horizonal surface and collides with a spring compressing it a distance x. The spring will compress 1 meter with an applied force of 400 Newtons A. Calculate the speed of the block at the halfway down the incline? B. Calculate the speed of the block at the bottom of the incline? C. How much work is done...
SPRING PE PRACTICE • A person uses a 10 kg block to compress a spring (with spring constant 8000 N/m) by 0.1 meters. The block is then released and slides along a frictional ramp (lk = 0.2). How far along the ramp does the block slide before coming to a stop? Ax = ? Hy = 0.2 < 0.2 10 kg ww10t04 370
A 5 kg block and a 1 kg block are stacked on top of a spring, causing it to compress by 0.2 m. The 1 kg block is then removed while the spring is kept compressed at 0.2 m. The 1 kg block is then dropped from 1.5 m above the 5 kg block. When the 1 kg block hits the 5 kg block, the two blocks stick together. How much further does the spring compress before the blocks come...
A 13.0 kg stone slides down a snow-covered hill, leaving point A with a speed of 11.0 m/s . There is no friction on the hill between points A and B, but there is friction on the level ground at the bottom of the hill, between B and the wall. After entering the rough horizontal region, the stone travels 100 m and then runs into a very long, light spring with force constant 2.10 N/m . The coefficients of kinetic...
