Homework Answers
R' = 6 + 3 = 9 ohm
R" = (9 x 3)/(9 + 3) = 2.25 ohm
Current, I = 12/2.25 = 5.33 A
A)
Current through R3, I3 = 12/3 = 4 A
B)
Current through R' = 5.33 - 4 = 1.33 A
Voltage across R1, V1 = 1.33 x 6 = 7.98 V
Comment in case any doubt please rate my answer....
Add Answer to:
olumns, and Ry olums are connected to a 12 V battery as shown in the circuit...
The circuit shown in the figure below contains three resistors (Ry, Ry, and R) and three...
The circuit shown in the figure below contains three resistors (Ry, Ry, and R) and three batteries (V, V, and V). The resistor values are: R2-2 Ohms, R, Ry-8 Ohms, and the battery voltages are VA 25V, V. 15 V, and Vc 20V. When the circuit is connected, what will be the power dissipated by Ry? Vc R R2 R3 O 0.75 W O 1.25 W O 2.67 w 42 w O 5.5 W
The circuit shown in the figure below contains three resistors (Ry, Ry, and R) and three...
The circuit shown in the figure below contains three resistors (Ry, Ry, and R) and three batteries (VA. Vg, and Vc). The resistor values are: R2-2 Ohms, R2-R3-4 Ohms, and the battery voltages are VA-25V, V -15V, and Vc-20 V. When the circuit is connected what will be the current through R22 Vc R th R2 R 0.75 A 1.25 A 2.5 A 3.0 A 3.75 A
The circuit shown in the figure below contains three resistors (R4, Ry, and R) and three...
The circuit shown in the figure below contains three resistors (R4, Ry, and R) and three batteries (V, Vs, and VJ. The resistor values are: Ry=2 Ohms, Ry=R3=6 Ohms, and the battery voltages are VA-25V, V, 15 V, and Vc=20 V. When the circuit is connected, what will be the power dissipated by R ? VC R R2 R3 O 10W © 20W 05.0W 06.0W 7.5 W
Shown in the circuit below is a V= 10.0 V battery connected with three resistors and...
Shown in the circuit below is a V= 10.0 V battery connected with
three resistors and a switch. The resistances for each resistor are
R1= 10 ohms, R2= 100 ohms, and R3=
1.0 ohms.
B) Calculate the current through each resistor when the switch
is closed.
A) Calculate the equivalent resistance when 1) the switch is
open and 2) when the switch is closed.
E R, Ion 2 loon R
In the circuit shown above, a battery with a voltage ?Vbat = 24 V is connected...
In the circuit shown above, a battery with a voltage ?Vbat = 24 V is connected to the circuit with resistances R1 = 5 Ohms, R2 = 35 Ohms, and R3 = 32 Ohms. The volt meter measures the potential difference between the points A and B, ?VAB. What is the power lost in the resistor R3? Give your answer in Watts to three signficant digits. Do not include units in your answer.
Consider a circuit with three resistors in series connected to a 15.6 V battery. If R1...
Consider a circuit with three resistors in series connected to a 15.6 V battery. If R1 = 40.5 ohms, R2 = 54.8 ohms, and R3 = 30.8 ohms, what is the voltage across R2? Calculate the answer in volts (V) and rounded to three significant figures. please explain.
The circuit shown in the figure below contains three resistors (R1, R2, and R3) and three...
The circuit shown in the figure below contains three resistors (R1, R2, and R3) and three batteries (VA. Vg, and V). The resistor values are: R1=2 Ohms, Ry=R3=8 Ohms, and the battery voltages are VA=25 V, Vo=15 V, and Vc=20 V. When the circuit is connected, what will be the power dissipated by R3? Vc RA VA VB R2 R3
The circuit shown in the figure below contains three resistors (R1, R2, and Rg) and three...
The circuit shown in the figure below contains three resistors (R1, R2, and Rg) and three batteries (VA, Ve, and V). The resistor values are: R=2 Ohms, R2=R3=4 Ohms, and the battery voltages are VA-25V, V =15 V, and Vc 20 V. When the circuit is connected, what will be the power dissipated by Ry? Vc R1 - Ve R₂ R O 1.25 W O 20w O 12.5 W O 6.25 W 8.13 W
The circuit shown in the figure below contains three resistors (R4, R2, and Rg) and three...
The circuit shown in the figure below contains three resistors (R4, R2, and Rg) and three batteries (VA. Vg, and V). The resistor values are: R,-2 Ohms, R-R3-4 Ohms, and the battery voltages are VA-25V, Vp-15 V, and Vc-20V. When the circuit is connected, what will be the power dissipated by Ry? Vc A R R R3 O 1.25 W O 20W O 50W O 6.25 W O 8.13 W
The voltage of the battery is 12 V, and the values of the resistances are: R1...
The voltage of the battery is 12 V, and the values of the
resistances are: R1 = 5 ohms, R2 = 10 ohms,
R3 = 15 ohms, and R4 = 20 ohms.
11) R1 and R4
are in:
parallel
series
neither
+ HE MW R2 M WWW R R4 WWW R3
The circuit shown in the figure below contains three resistors (Ry, Ry, and R) and three batteries (V, V, and V). The resistor values are: R2-2 Ohms, R, Ry-8 Ohms, and the battery voltages are VA 25V, V. 15 V, and Vc 20V. When the circuit is connected, what will be the power dissipated by Ry? Vc R R2 R3 O 0.75 W O 1.25 W O 2.67 w 42 w O 5.5 W
The circuit shown in the figure below contains three resistors (Ry, Ry, and R) and three batteries (VA. Vg, and Vc). The resistor values are: R2-2 Ohms, R2-R3-4 Ohms, and the battery voltages are VA-25V, V -15V, and Vc-20 V. When the circuit is connected what will be the current through R22 Vc R th R2 R 0.75 A 1.25 A 2.5 A 3.0 A 3.75 A
The circuit shown in the figure below contains three resistors (R4, Ry, and R) and three batteries (V, Vs, and VJ. The resistor values are: Ry=2 Ohms, Ry=R3=6 Ohms, and the battery voltages are VA-25V, V, 15 V, and Vc=20 V. When the circuit is connected, what will be the power dissipated by R ? VC R R2 R3 O 10W © 20W 05.0W 06.0W 7.5 W
Shown in the circuit below is a V= 10.0 V battery connected with
three resistors and a switch. The resistances for each resistor are
R1= 10 ohms, R2= 100 ohms, and R3=
1.0 ohms.
B) Calculate the current through each resistor when the switch
is closed.
A) Calculate the equivalent resistance when 1) the switch is
open and 2) when the switch is closed.
E R, Ion 2 loon R
The circuit shown in the figure below contains three resistors (R1, R2, and R3) and three batteries (VA. Vg, and V). The resistor values are: R1=2 Ohms, Ry=R3=8 Ohms, and the battery voltages are VA=25 V, Vo=15 V, and Vc=20 V. When the circuit is connected, what will be the power dissipated by R3? Vc RA VA VB R2 R3
The circuit shown in the figure below contains three resistors (R1, R2, and Rg) and three batteries (VA, Ve, and V). The resistor values are: R=2 Ohms, R2=R3=4 Ohms, and the battery voltages are VA-25V, V =15 V, and Vc 20 V. When the circuit is connected, what will be the power dissipated by Ry? Vc R1 - Ve R₂ R O 1.25 W O 20w O 12.5 W O 6.25 W 8.13 W
The circuit shown in the figure below contains three resistors (R4, R2, and Rg) and three batteries (VA. Vg, and V). The resistor values are: R,-2 Ohms, R-R3-4 Ohms, and the battery voltages are VA-25V, Vp-15 V, and Vc-20V. When the circuit is connected, what will be the power dissipated by Ry? Vc A R R R3 O 1.25 W O 20W O 50W O 6.25 W O 8.13 W
The voltage of the battery is 12 V, and the values of the
resistances are: R1 = 5 ohms, R2 = 10 ohms,
R3 = 15 ohms, and R4 = 20 ohms.
11) R1 and R4
are in:
parallel
series
neither
+ HE MW R2 M WWW R R4 WWW R3
