An electron (charge (e) = 1.6 x 10-19 C, mass (me = 9.1 x 10-31 kg)...

Question

Question

An electron (charge (e) = 1.6 x 10-19 C, mass (me = 9.1 x 10-31 kg) that trapped inside a magnetic field observed m oving at

science physics

Answer 1

Answer #1

V = 3x104m/s MV Q VA sino = R R - MV q B singoº (9.1 XIO - 631)(3x104) 1.6 x 16 x 1.4 x 1 -19 R = 0.122 x meter 10°6 llm ® o.

Answer 2

Similar Homework Help Questions

An electron with a mass of 9.1 x 10-31 kg; and a of charge 1.6 x...

An electron with a mass of 9.1 x 10-31 kg; and a of charge 1.6 x 10-19 C is located at the origin of coordinates (x=0;y=0;z=0) at time t=0. At time t=0, the electron has a velocity of 4.0x105 m/s along the +x axis in the horizontal plane. Also, at this time, the electron enters a region of space with a magnetic field of 3.0 x 10-5 T pointing in the +z direction. What is the location of the electron...
An electron (mass m = 9.11 x 10-31 kg, charge e = 1.6 x 10-19 C)...

An electron (mass m = 9.11 x 10-31 kg, charge e = 1.6 x 10-19 C) are accelerated from rest through a potential difference V = 450 V and are then deflected by a magnetic field (B = 0.4 T) that is perpendicular to their velocity. The radius of the resulting electron trajectory is:
6. An electron of mass 9.1 x 10-31 kg and charge -1.6 x 10-19 C rotates...

6. An electron of mass 9.1 x 10-31 kg and charge -1.6 x 10-19 C rotates around the nucleus of the hydrogen atom in a circular orbit of radius 5.3 x 10-1lm. (a). Write down the equation of motion for the electron (F-ma) specifically for this physical situation; the constant in Coulomb's law is k 9x 10 Nm/C2. Using this result, find the time for the electron to make one complete circular orbit. (b). An electron's rotation creates an effective...

An electron (m_p = 9.1 times 10^-31 kg, q_p = -1.6 times 10^-19 C) travels at...

An electron (m_p = 9.1 times 10^-31 kg, q_p = -1.6 times 10^-19 C) travels at 4 times 10^5 m/s in a direction perpendicular to a uniform 3.0 mT magnetic field. What is the diameter of its path? Two long straight wires each carrying a current of 200 A in the same directions are separated by a distance of 40 cm. Calculate the force on a 2m long section of wire. Is the force attractive or repulsive? An electron is...
An electron (charge -1.6 x 10^-19 C) moves on a path perpendicular to the direction of...

An electron (charge -1.6 x 10^-19 C) moves on a path perpendicular to the direction of a uniform electric field of strength 3.0 N/C. How much work is done on the electron as it moves 15 cm? 4.8 x 10^20 J 0.55 x 10^20 J 0.72 x 10^-20 J
At one instant an electron (charge = –1.6 x 10–19 C) is moving in the xy...

At one instant an electron (charge = –1.6 x 10–19 C) is moving in the xy plane, the components of its velocity being vx = 5.0 x 105 m/s and vy = 3.0 x 105 m/s. A magnetic field of 0.80 T is in the positive x direction. At that instant the magnitude of the magnetic force on the electron is:

An electron (charge= -1.6 x 10^-19 C) is moving at 3 x 10^5 m/s in the...

An electron (charge= -1.6 x 10^-19 C) is moving at 3 x 10^5 m/s in the positive x direction. A magnetic field of 0.8 T is in the positive z direction. What are the magnitude and direction on the magnetic force on the electron?
An electron (charge≈ 1.602 × 10−19 C; mass≈ 9.109 × 10−31 kg) moving at speed 200...

An electron (charge≈ 1.602 × 10−19 C; mass≈ 9.109 × 10−31 kg) moving at speed 200 m/s finds itself in a region of constant magnetic field. The magnetic field points perpendicular to the electron velocity and has strength 10−3 Tesla. (a) Find the magnitude of the magnetic force experienced by the electron. (b) The magnetic force causes cyclotron motion, so that the electron moves around a circular trajectory. Find the radius of the circular trajectory. (c) How long does it...
2. A proton with charge gp 1.6 x 10 19C and mass M, is accelerated through...

2. A proton with charge gp 1.6 x 10 19C and mass M, is accelerated through a potential difference V. The proton then enters a region of con stant magnetic field B oriented perpendicular to its path. In this region, the proton's path is circular with radius Rp Another particle with the same charge as the proton but a different mass M, follows under the same conditions. Its radius R., is 1.4 times as large as Rp. what is the...

An electron of mass me 9.11 x 10-31 kg and a charge of ge1.60 x 10-19...

An electron of mass me 9.11 x 10-31 kg and a charge of ge1.60 x 10-19 C is released, from rest, in a region of uniform electric field that points to the right with a magnitude of IE -6.06 N/C. How long does it take for the electron to reach a speed of 7.00 x 104 m/s? Assume the experiment is performed in a vacuum and that you can ignore the effects of gravity and friction. Give you answer in...
