Need help on these 3. stuck 1. A copper wire has a diameter of 2.415 mm....
Need help on these 3. stuck
1. A copper wire has a diameter of 2.415 mm. What magnitude current flows when the drift velocity is 3.79 mm/s? Take the density of copper to be 8.92x103 kg/m3. Give your answer in Amperes?
2. A jeweler uses a draw plate to stretch a wire to 9 times its original length. By what factor does its resistance increase?
Homework Answers
Add Answer to:
Need help on these 3. stuck
1. A copper wire has a diameter of 2.415 mm....
A 14-gauge copper wire has a diameter of 1.684 mm. What magnitude current flows in amperes...
A 14-gauge copper wire has a diameter of 1.684 mm. What magnitude current flows in amperes when the drift velocity is 1.20 mm/s? (The density of free electrons in copper is 8.34 ✕ 1028 e−/m3.).) ____________ A
A copper wire has a diameter of 1.350 mm. What magnitude of current flows when the...
A copper wire has a diameter of 1.350 mm. What magnitude of current flows when the drift velocity is 3.09 mm/s? Take the density of copper to be 8.92 g/cm3. Give your answer in Amperes.
ponit osun Phys1 26.2. WA.011. Tutorial A copper wire has a diameter of 1.447 mm. What...
ponit osun Phys1 26.2. WA.011. Tutorial A copper wire has a diameter of 1.447 mm. What magnitude current flows when the drift speed is 1.64 mm/s? Take the density of copper to be 8.92 x 10 kg/m Additional Materials Tutorial
A 14 gauge copper wire has a diameter of 1.628 mm. What magnitude current flows when...
A 14 gauge copper wire has a diameter of 1.628 mm. What magnitude current flows when the drift velocity is 1.07 mm/s?
A 0.68-mm-diameter copper wire carries a tiny current of 2.4 μA . The molar mass of...
A 0.68-mm-diameter copper wire carries a tiny current of 2.4 μA . The molar mass of copper is 63.5 g/mole and its density is 8900 kg/m3. NA=6.02×1023. Estimate the electron drift velocity. Assume one free electron per atom.
1. A number 12 copper wire has a diameter of 2.053 mm. Calculate the resistance of...
1. A number 12 copper wire has a diameter of 2.053 mm. Calculate the resistance of a 37.0 m long piece of such wire. (Use 1.72×10-8 Ωm for the resistivity of copper.) Use the formula for resistance remembering that the diameter is specified rather than the radius. 2. For safety, the National Electrical Code limits the allowable amount of current which such a wire may carry. When used in indoor wiring, the limit is 20.0 A for rubber insulated wire...
Copper wire has a diameter of 1.02 mm. It carries a current of 1.67 A to...
Copper wire has a diameter of 1.02 mm. It carries a current of 1.67 A to a 200 W bulb. The density of free electrons is 8.5x10^28 electrons per cubic meter. Find a) the current density and b) the drift velocity
20.16 - Current A 14.0-gauge copper wire has a diameter of 1.628 mm. What magnitude current...
20.16 - Current A 14.0-gauge copper wire has a diameter of 1.628 mm. What magnitude current flows when the drift velocity is 1.41 mm/s? (See Example 20.3 for useful information.) 22.2A Submit Anser Incorrect. Tries 3/10 Previous Tries
20.16 - Current A 14.0-gauge copper wire has a diameter of 1.628 mm. What magnitude current...
20.16 - Current A 14.0-gauge copper wire has a diameter of 1.628 mm. What magnitude current flows when the drift velocity is 1.41 mm/s? (See Example 20.3 for useful information.) 22.2A Submit Anser Incorrect. Tries 3/10 Previous Tries
Consider a straight piece of copper wire of length 8 m and diameter 8 mm that...
Consider a straight piece of copper wire of length 8 m and diameter 8 mm that carries a current I = 4.5 A. There is a magnetic field of magnitude B directed perpendicular to the wire, and the magnetic force on the wire is just strong enough to “levitate” the wire (i.e., the magnetic force on the wire is equal to its weight). Find B. Hint: The density of copper is 9000 kg/m3 .
ponit osun Phys1 26.2. WA.011. Tutorial A copper wire has a diameter of 1.447 mm. What magnitude current flows when the drift speed is 1.64 mm/s? Take the density of copper to be 8.92 x 10 kg/m Additional Materials Tutorial
20.16 - Current A 14.0-gauge copper wire has a diameter of 1.628 mm. What magnitude current flows when the drift velocity is 1.41 mm/s? (See Example 20.3 for useful information.) 22.2A Submit Anser Incorrect. Tries 3/10 Previous Tries
20.16 - Current A 14.0-gauge copper wire has a diameter of 1.628 mm. What magnitude current flows when the drift velocity is 1.41 mm/s? (See Example 20.3 for useful information.) 22.2A Submit Anser Incorrect. Tries 3/10 Previous Tries
