A 0.68-mm-diameter copper wire carries a tiny current of 2.4 μA . The molar mass of...
A 0.68-mm-diameter copper wire carries a tiny current of 2.4 μA . The molar mass of copper is 63.5 g/mole and its density is 8900 kg/m3. NA=6.02×1023.
Estimate the electron drift velocity. Assume one free electron per atom.
Homework Answers
Add Answer to:
A 0.68-mm-diameter copper wire carries a tiny current of 2.4 μA
. The molar mass of...
plz keep in mind sig figures :) A 0.70-mm-diameter copper wire carries a tiny current of...
plz keep in mind sig figures :)
A 0.70-mm-diameter copper wire carries a tiny current of 2.6 uA . The molar mass of copper is 63.5 g/mole and its density is 8900 kg/m' NA = 6.02 x 1023 Part A Estimate the electron drift velocity. Assume one free electron per atom. Express your answer to two significant figures and include the appropriate units. uA ? vd = Value Units
1. Part A What is the diameter of a 1.00-m length of tungsten wire whose resistance...
1. Part A What is the diameter of a 1.00-m length of tungsten wire whose resistance is 0.45 Ω ? Express your answer using two significant figures. 2. Part A What is the maximum instantaneous power dissipated by a 3.4-hp pump connected to a 240-Vrms ac power source? 1 hp = 746 W. Express your answer using two significant figures. Part B What is the maximum current passing through the pump? Express your answer to two significant figures and include...
A 0.69 −mm -diameter copper wire carries a tiny current of 2.0 μA .
A 0.69 −mm -diameter copper wire carries a tiny current of 2.0 μA .
A. 1x10-10 m/s A 0.65 mm diameter copper wire carries a tiny current of 2.3 uA....
A. 1x10-10 m/s A 0.65 mm diameter copper wire carries a tiny current of 2.3 uA. Estimate the electron drift velocity. B. 7x10-10 m/s O C. 2x10-10 m/s O d. 5.1x10-10 m/s
The maximum rated current for a copper wire of cross-sectional area 2 mm^2 is 20A. (a)...
The maximum rated current for a copper wire of cross-sectional
area 2 mm^2 is 20A. (a) What is the corresponding current density
in A/m^2? (b) On the assumption that each copper atom contributes
one conduction electron, calculate the electronic drift velocity
corresponding to this current density. (Avogadro's number =
6.02E10^23 atoms per mole; atomic weight of copper = 63.5; density
of copper = 8.92 g/cm^3.) (c) Use the observed conductivity to
calculate the average collision time for an electron in...
Copper wire has a diameter of 1.02 mm. It carries a current of 1.67 A to...
Copper wire has a diameter of 1.02 mm. It carries a current of 1.67 A to a 200 W bulb. The density of free electrons is 8.5x10^28 electrons per cubic meter. Find a) the current density and b) the drift velocity
An 18-gauge copper wire (diameter 1.02 mm) carries a current with a current density of 1.40×106...
An 18-gauge copper wire (diameter 1.02 mm) carries a current with a current density of 1.40×106 A/m2 . Copper has 8.5×1028 free electrons per cubic meter Calculate the current in the wire Calculate the drift velocity of electrons in the wire.
Consider a copper wire with circular cross section with radius 0.5 mm, where the conduction electrons...
Consider a copper wire with circular cross section with radius 0.5 mm, where the conduction electrons in the wire have drift velocity 1 mm/s. Copper has a density of 8960 kg/m3, and copper atoms have a mass of 63.5 amu (where 1 amu = 1.67 x 10−27 kg). (a) How many copper atoms are in one cubic meter of copper wire? (b) Assume each copper atom provides one conduction electron (that is, for each copper atom, one electron is able...
A 14-gauge copper wire has a diameter of 1.684 mm. What magnitude current flows in amperes...
A 14-gauge copper wire has a diameter of 1.684 mm. What magnitude current flows in amperes when the drift velocity is 1.20 mm/s? (The density of free electrons in copper is 8.34 ✕ 1028 e−/m3.).) ____________ A
How many electrons are associated with a current of 15.0 A? Calculate the drift velocity of...
How many electrons are associated with a current of 15.0 A? Calculate the drift velocity of electrons in a 2.053 mm diameter copper wire carrying a 20.0 A current, given there is one free electron per copper atom. (Atomic mass of copper is 63.5 kg) (Density of copper is 8.80 x 103 kg/m3) If the resistance of a copper resistor is 20.0 W at 20.0 oC, find its resistance at 100 oC. A car headlight filament is made of tungsten...
plz keep in mind sig figures :)
A 0.70-mm-diameter copper wire carries a tiny current of 2.6 uA . The molar mass of copper is 63.5 g/mole and its density is 8900 kg/m' NA = 6.02 x 1023 Part A Estimate the electron drift velocity. Assume one free electron per atom. Express your answer to two significant figures and include the appropriate units. uA ? vd = Value Units
A. 1x10-10 m/s A 0.65 mm diameter copper wire carries a tiny current of 2.3 uA. Estimate the electron drift velocity. B. 7x10-10 m/s O C. 2x10-10 m/s O d. 5.1x10-10 m/s
The maximum rated current for a copper wire of cross-sectional
area 2 mm^2 is 20A. (a) What is the corresponding current density
in A/m^2? (b) On the assumption that each copper atom contributes
one conduction electron, calculate the electronic drift velocity
corresponding to this current density. (Avogadro's number =
6.02E10^23 atoms per mole; atomic weight of copper = 63.5; density
of copper = 8.92 g/cm^3.) (c) Use the observed conductivity to
calculate the average collision time for an electron in...
