How much force does it take to stretch a 20-m-long, 1.0 cm -diameter steel cable by...

Question

Question

How much force does it take to stretch a 20-m-long, 1.0 cm -diameter steel cable by 5.0 mm ?

Express your answer using two significant figures.

Thank you!

science physics

Answer 1

Answer #1

kindly give rating
