One rod is made from lead and another from quartz. The rods are heated and experience...

One rod is made from lead and another from quartz. The rods are heated and experience the same change in temperature. The change in length of each rod is the same. If the initial length of the lead rod is 0.18 m, what is the initial length of the quartz rod?

science   physics
0 0
Add a comment Improve this question Transcribed image text
Next > < Previous
Sort answers by oldest

Homework Answers

Answer #1

0 0
Add a comment
Know the answer?
Add Answer to:
One rod is made from lead and another from quartz. The rods are heated and experience...
Your Answer:

Post as a guest

Your Name:

What's your source?

Earn Coins

Coins can be redeemed for fabulous gifts.

Log In

Sign Up

Not the answer you're looking for? Ask your own homework help question. Our experts will answer your question WITHIN MINUTES for Free.
Similar Homework Help Questions

  • ône rod is made from lead and another from quartz. The rods are heated and experience...

    ône rod is made from lead and another from quartz. The rods are heated and experience the same change in temperature. The change in length of each rod is the same. If the initial length of the lead rod is 0.17 m, what is the initial length of the quartz rod? (The coefficients of linear expansion for quartz and lead are aq- 5.00 x 107 (cy1 and a-2.90 x 10s (y1, respectively.) LQ SselectDGO Tutorla

  • one md-made fom lead and another nom quarte, rods are heated and experience the same change...

    one md-made fom lead and another nom quarte, rods are heated and experience the same change in temperature. The change in length of each rod is the same. If the initial h of the lead rod. O 14 m, what a t e initial length or me quartz od? (The coemcents of linear expansion fy quarte and lead are 41.-5.00 × 10 7 (C.)-1 and a,-2.90 × 10 s (C*) 1, respectively.)

  • Z Your answer is partially correct. Try again. One rod is made from lead and another...

    Z Your answer is partially correct. Try again. One rod is made from lead and another from quartz. The rods are heated and experience the same change in temperature. The change in length of each rod is the same. If the initial length of the lead rod is 0.19 m, what is the initial length of the quartz rod? 1.10 La the tolerance is +/-7%

  • Two rods of the same length Rod 1 and diameter are made from different materials. The...

    Two rods of the same length Rod 1 and diameter are made from different materials. The rods are Ti to connect two regions of different temperature so that energy will transfer through the rods by heat. They can be connected in series, as in Figure (e), or in parallel, as in Figure (b), In which case is the rate of energy transfer by heat larger? T. T. Rod1Rod 2 Rod 2 a)When the rods are in series. b) When the...

  • A lead object and a quartz object each have the same initial volume. The volume of...

    A lead object and a quartz object each have the same initial volume. The volume of each increases by the same amount, because the temperature increases. If the temperature of the lead object increases by 3.5 °C, by how much does the temperature of the quartz object increase? (The coefficient of volume expansion for lead is 8.70 × 10 − 5 o C − 1 and that one for quartz is 1.50 × 10 − 6 o C − 1...

  • A lead object and a quartz object each have the same initial volume. The volume of...

    A lead object and a quartz object each have the same initial volume. The volume of each increases by the same amount, because the temperature increases. If the temperature of the lead object increases by 4.3 °C, by how much does the temperature of the quartz object increase? (The coefficient of volume expansion for lead is 8.70×10−58.70×10−5 oC−1oC−1 and that one for quartz is 1.50×10−61.50×10−6 oC−1oC−1 ) the answer is not 249.4

  • A rod with an initial length of 4.88 m i heated from a temperature of 4...

    A rod with an initial length of 4.88 m i heated from a temperature of 4 °C to 52 °C. The material has a linear coefficient of thermal expansion of 0.000093 °C-1. What is the new total length of the rod? Answer: Check

  • Exercise 17.56 Two rods, one made of brass and the other made of copper, are joined...

    Exercise 17.56 Two rods, one made of brass and the other made of copper, are joined end to end. The length of the brass section is 0.200 m and the length of the copper section is 0.800 m. Each segment has cross-sectional area 0.00700 m2 The free end of the brass segment is in boiling water and the free end of the copper segment is in an ice-water mixture, in both cases under normal atmospheric pressure. The sides of the...

  • A rod with a length of 1.6 m is made of brass, which has a coefficient...

    A rod with a length of 1.6 m is made of brass, which has a coefficient of linear expansion of 1.90 ✕ 10−5 (°C)−1. It is initially at a temperature of 27°C. What is the change in length of the rod if the temperature drops to 0.0 C? ( give absolute value in units of mm) Find the absolute value of the fraction by which the rods length changes between two temperatures. ΔL L0

  • Two rods of the same length and diameter are made from copper and aluminium, respectively. The...

    Two rods of the same length and diameter are made from copper and aluminium, respectively. The rods are connected in series and to two regions of different temperature so that energy will transfer through the rods by heat. The temperature Th is maintained at a constant 84.0 °C at the end A while the temperature Tc at the end B is maintained at 19.0 °C. The thermal conductivity of copper is 397 J/(s · m · °C) and that for...
