The moment of inertia of a disk rotating about its axis of symmetry is Icm=1/2MR^2 The...

The moment of inertia of a disk rotating about its axis of symmetry is Icm=1/2MR^2

The formula for finding the moment of inertia of an object rotating off axis if its on axis center of mass moment of inertia is I=Icm + Md^2

Given a disk 10cm in diameter whose mass is 1500g, find its off-axis moment of inertia if the disk is located 10cm from the axis rotation.

science   physics
0 0
Add a comment Improve this question Transcribed image text
Next > < Previous
Sort answers by oldest

Homework Answers

Answer #1

0 0
Add a comment
