10. A 6.0kg block is pushed 1.2m along a frictionless table. A 24N force is applied...

Question

Question

10. A 6.0kg block is pushed 1.2m along a frictionless table. A 24N force is

applied directed 15◦ below the horizontal.

a. What is the work done on the block by the 24N applied force?

b. What is the work done on the block by the normal force?

c. What is the work done on the block by the gravitational force?

d. What is the net work done on the block?

I have the answers. I Really need to see the work.

science physics

Answer 1

Answer #1

Answer 2
